System Maintenance
Table 3‐1showstheLEDconditionsthatspecifythefaileddrive.
3.1.1 Replacing a Drive
ToreplaceaDP600harddrive:
1. Lookatthefront‐paneldriveLEDs,thenrefertoTable 3‐1todeterminewhichdrive
hasfailed.
Figure3‐1 
Figure 3-1 Red LED Indicates Failed Disk Drive
Table 3-1 Local Storage LED Conditions
Front-Panel LED Condition Failed Physical Drive
1Solidred 1
1Blinksinredin
two‐secondintervals
2
1Blinksinredin
half‐secondintervals
RebuildingRAID
2Solidred 3
3Solidred 4
4Solidred 5
!
4
3
2
1
Failed drive
red LED
