Introduction
1.6 DP600 Rear Panel
TheDP600rearpanelincludesthefollowingcomponents:
•Dual‐redundantpowersupplies(withredalarmresetbutton)
•TwoPS/2ports—ToconnectaPS/2keyboardand/ormouse
•FourUSB2.0ports—ToconnectaUSBflashdriveforlicenseloadingand/oraUSB
keyboardandmouse
•Two10 /100/1000BASE‐TEthernetports(withaut o‐detection)—Toconnect

toyournetwork(upperportcurrentlyactive,lowerportreservedforfutureuse)
•SVGAmonitorport—Toconnectamonitor,whichmirrorsthefront‐paneltouch
screen
•Twofa ns
•Twoserialports(forfutureuse)
•Audioports(forfutureuse)
•ThreeemptyPCIslots(forfutureuse)
Figure 1‐5showsthecurrentlyactivecomponents
ontheDP600rearpanel.
Figure1‐5 
Figure1‐6 
Figure 1-5 DP600 Rear Panel
Dolby and the double-D symbol are registered trademarks of Dolby Laboratories.
Dolby and the double-D symbol are registered trademarks of Dolby Laboratories.
Risk of electric shock.
Do not open.
This equipment must be
earthed/grounded.
No user serviceable parts
inside. Refer all service
to qualified personnel.
WARNING
100–240Vac
3.0–1.25A 50/60Hz
MAINS INPUT
MAINS INPUT
Model DP600
Model DP600
Program Optimizer
Program Optimizer
Power Supply
Alarm Reset
Power Supply
Alarm
Reset
PS/2 ports
USB 2.0 ports
Monitor port
Fans
Power supplies
Active Ethernet port (upper port)
Red alarm reset button
