Business

The fast 100-ppm* scan speed and 300-page Automatic
Document Feeder are ideal for both large-volume scanning
and dispersed input. The paper feed mechanism, which is
equipped with unique Panasonic technologies, also helps to
minimise damage to important documents and ensures more
precise feeding. And three labor-saving functions boost work
efficiency by letting the user easily obtain optimal images.
* A4, Landscape, 200/300 dpi, Binary/Colour.
* There is a limit to the skewing correction. Skewing reduction is effec-
tive for documents that are skewed up to approximately 5 degrees.
Physical paper skewing is reduced by the
integrated Mechanical Deskew system. Even
when skewed documents are fed into the
scanner, the Mechanical Deskew system
physically adjusts the paper before the paper is
scanned by the CIS (Contact Image Sensor).
Multiple sensors are used to detect various types of stapled
documents, and to immediately stop the scanner when stapling
is detected. This minimises damage to both the document and
the optical glass.
The KV-S5076H is equipped with an ultrasonic sensor, which
accurately detects double-feeding even when scanning
documents of various thicknesses. When detected, the
ultrasonic sensor prevents double-feeding by immediately
stopping the scanning process.
Any lifting of the document is detected.
The sensor detects double-feeding and stops the scanner immediately. The high-performance sensor catches even subtle changes.
Separation Roller
Paper Feed Roller
Double Feed Prevention Roller
The paper feed roller separates from
the paper each time a sheet is fed.
When paper sliding is detected, the
double feed prevention roller pressure
is increased.
The paper feed rollers separate from the paper each time a
sheet is fed, so the tendency to double-feed caused by the
paper feed roller pressure is reduced, even when feeding paper
of different thicknesses. Any paper sliding is also detected
and the double feed prevention roller pressure is adjusted to
prevent the paper from slipping and jamming.
The paper exit roller reduces the speed
of the paper being ejected and aligns the
paper to prevent paper jams or the loss
of originals.
Quick, Accurate, Smart.
Ideal for Large-Volume
Text-to-Data Conversion.
Mechanical Deskew* Paper Ejection Control
Stapled Document Detection
Ultrasonic Double-Feed Detection
Superior Roller Mechanisms
Preventing Damage to the Scanning Glass
Accurate Scanning
Precise Feeding
Innovative Paper Feed Mechanism
Staples are quickly and accurately detected, to minimise damage to the optical glass and the document.
Corner Staple Side Staple
Transmitter
Receiver
Feed Direction
The Paper Exit Roller
5°
