User manual

DMXking.com • JPK Systems Limited • New Zealand
0077-700-1.3
2
Important Note: eDMX1 PoE will require either an 802.3af compliant network switch or power injector. See DMXking.com
accessories.
STATUS LED TABLE
Lower LED Indication
ON Network link.
FLASH Network activity.
Upper LED Indication
Slow FLASH Green Power ON indication. Waiting for network connection.
FLASH Red Receive mode, DMX512 stream detected. Flash rate = DMX update rate.
FLASH Green Transmit mode, Art-Net/sACN DMX512 stream received. Flash rate = DMX rate.
ON Firmware update mode initiated. Power off/on to exit.
3. DEFAULT CONFIGURATION
All eDMX1 units ship with default IP address settings. Please reconfigure for your requirements before use!
Parameter Default Setting
IP Address 192.168.0.111
Subnet Mask 255.255.255.0
Default Gateway 192.168.0.254
DMX512 and Art-Net / sACN configuration parameters are also configured with default values.
Parameter Default Setting
Network Mode Custom IP address
Operation Mode DMX Out
DMX Universe 1 [Net 00, Subnet 0, Universe 0]. Note sACN Universe 1 = Art-Net 00:0:0
Art-Net Merge Mode HTP
DMX512 Update Rate
40 [DMX512 frames per second]
RDM Packet Spacing 1/20s
RDM Discovery Period 0s
Broadcast Threshold 0 [Force Art-Net 1 broadcast]. Don’t change this unless you want Art-Net II/III
unicast on DMX In ports.
