6. TECHNICAL SPECIFICATIONS
• Dimensions: 60x36x78mm (WxHxD)
• Weight: 0.13kg
• DMX512 connector: 3 or 5 pin XLR Female.
• Internal DMX512 RDM compliant line biasing 120Ω termination.
• Power connector: USB mini-B socket (only active on eDMX1 PoE with internal jumper selection)
• Power over Ethernet 802.3af compliant (eDMX1 PoE only).
• Art-Net, Art-Net II, Art-Net III and sACN/E1.31 support.
• ANSI E1.20 RDM compliant with RDM over Art-Net.
• Both HTP and LTP merging of 2 Art-Net/sACN streams
• IPv4 Addressing
• DMX512 Frame Rate: Adjustable
• DMX512 Port Protection: DMX512-A Protected as per E1.11-2008
7. WARRANTY
DMXKING.COM HARDWARE LIMITED WARRANTY
What is covered
This warranty covers any defects in materials or workmanship with the exceptions stated below.
How long coverage lasts
This warranty runs for one year from the date of shipment from an authorized DMXking.com distributor.
What is not covered
Failure due to operator error or incorrect application of product. Opening the unit voids the warranty.
What DMXking.com will do
DMXking.com will repair or replace, at its sole discretion, the defective hardware. Return shipping costs from our service facility
in New Zealand shall be free of charge.
How to obtain service
Contact DMXking.com directly by email [e-mail]
8. DECLARATIONS (FCC & CE)
FEDERAL COMMUNICATIONS COMMISSION (FCC) DECLARATION OF CONFORMITY
Responsible Party: JPK Systems Limited
PO Box 493
Pukekohe 2340
New Zealand
