65VN01 V2 Ver. 1.2

19/24

065VN01 V2

7. Connector & Pin Assignment

7.1 TFT- LCD Signal (CN1): LCD Connector

anufacturer STM

Connector Model Number MSB24013P20, compatible with I-PEX 20268-020E

Mating Connecter Model Number Hirose DF19 -20S-1C or compatible

Pin# Symbol Pin# Symbol

1 VDD 11 RxIN3-

2 VDD 12 RxIN3+

3 GND 13 GND

4 SEL68 14 RxCLKIN-

5 RxIN1- 15 RxCLKIN+

6 RxIN1+ 16 NC

7 GND 17 U/D

8 RxIN2- 18 R/L

9 RxIN2+ 19 RxIN4-

10 GND 20 RxIN4+

7.2 LED Backlight Unit (CN2): Backlight Connector

anufacturer STM

Connector Model Number MS24016RHD, compatible with MOLEX 53261-0671

Mating Connecter Model Number STM P24016 or compatible

Pin #

Symbol Pin # Symbol

1 V

LED

4 GND

2 V

LED

5 LED ON/OFF

3 GND 6 PWM DIM
