Manual

In the Box

Gimbal ×1

In the mechanical structure, the gimbal has built-in slip rings,

preventing wire rod from winding up, which also enables free

rotations for the 3 axes rotating rods.

The gimbal has built-in Z15 gimbal special servos drive module,

independent IMU module and HDMI－AV module.

Gimbal Controller Unit (GCU)×1

Connect the gimbal controller to the flight control system by

CAN- Bus. The GCU will control the gimbal’s pan, roll and tilt

rotation.

Lens Retaining Ring×1

For fixing the camera lens.

Mounting Bracket ×4

For gimbal and landing gear connection.

Mounting Board for Receiver ×1

For fixing the GCU, and providing the mounting position for the

receiver or other device.

Cable Clamp ×1

For tidying the cables on gimbal.

Camera Mount Screw×1
