Product Profile

Z15 is an excellent gimbal designed for Aerial Photography. It has built-in slip rings within the mechanical structure,

preventing the wire rod from entangling. The gimbal has an integrated independent IMU module, a special servos

drive module, etc., which are dedicated to provide excellent performance in any working modes, including

Orientation-locked control, Non orientation-locked control and FPV Mode (Reset).

Working Mode

Orientation-locked Mode

Non orientation-locked Mode

FPV Mode

(Reset)

Gimbal Point

Gimbal point stays locked

with aircraft nose direction

Gimbal point stays unchanged

when aircraft nose direction

changes.

Gimbal point stays the

same as aircraft nose

direction when powered

Gimbal and

Aircraft Nose

Relative Angle

Gimbal point keeps the

same relative angle with the

aircraft nose direction

Relative angle between the

gimbal point and aircraft nose

direction may change

Zero relative angle

between the gimbal point

and aircraft nose

TX Control

Controlled

Not controlled

Attitude stability

YES

Vibration

Reduction

YES

Stick Meaning

Command stick stands for

gimbal rotation velocity，

Stick center position is for

0，its endpoint is maximum

velocity.

Command stick stands for

gimbal rotation velocity，Stick

center position is for 0，its

endpoint is maximum velocity.

——

Command

Linearity

YES

——

Note1: ‘Gimbal point’ refers to the

gimbal PAN rotation direction

Note2: ‘Attitude stability’ means the

gimbal’s ROLL/TILT will not follow the aircraft’s ROLL/PITCH

Note3: ‘Gimbal rotating maximum velocity’ is corresponding to the

TX 100% end-point
