Specications
DJI Goggles RE
Weight (Typical)
Goggles RE Body: 502 g
Headband: 500 g
Dimensions
Goggles RE Body: 195×155×110 mm
Headband (folded): 255×205×92 mm
Screen Size 5 inch×2
Screen Resolution 3840×1080 (single screen: 1920×1080)
Refresh Rate 60 Hz
FOV 85° (single screen)
Interpupillary Distance Range 58 – 70 mm
Communication Frequency 2.4 GHz / 5.8 GHz
Transmitter Power (EIRP)
2.4 GHz: 25.5 dBm (FCC); 18.5 dBm (CE); 19 dBm (SRRC)
5.8 GHz: 25.5 dBm (FCC); 12.5 dBm (CE); 18.5 dBm (SRRC)
Max. Transmission Distance Same as the aircraft connected
Live View Modes 1080p30, 720p60, 720p30
Min. Video Downlink Latency
(near eld, free of interference)
110 ms (Mavic Pro, 720p60, video format: 720p120)
150 ms (Spark, 720p30, video format: 1080p30)
150 ms (Phantom 4 Pro/Advanced Series, 720p60,
video format: 720p60/720p120)
167 ms (Phantom 4, 720p30, video format: 720p60)
140 ms (Inspire 2+X5S, 720p60, video format: 1080p120)
190 ms (Inspire 2+X4S, 720p60, video format: 1080p60)
Video Format MP4 (H.264)
Supported Video Play Format
MP4, MOV, MKV (Video format: H264;
Audio format: AAC-LC, AAC-HE, AC-3, DTS, MP3)
I/O Interface
SMA port, Micro USB port, 3.5 mm Audio port, HDMI Type-D
port, Micro SD Card slot
HDMI Supported HDMI 1.4b, HDCP 1.4
Sensors Gyroscope, Accelerometer, Proximity Sensor
Operating Temperature Range 32° to 104° F (0° to 40° C)
Battery Capacity 9440 mAh
Battery Energy 35.44 Wh
Max. Operating Time 6 hrs
Charger
Input: 100-240 VAC, 50/60 Hz, 0.5 A
Output: 5 V
3 A / 9V 2A / 12 V 1.5 A
