User Manual

14
©
2017 DJI All Rights Reserved.
DJI Goggles Racing Edition User Manual
If the remote controller and Goggles RE are operated by one person but for two users, a
spotter who is able to instruct and give warning is required for safe ying.
Only the primary remote controller can switch ight modes.
Secondary Goggles RE do not support head tracking.
If two operators control the aircraft simultaneously, the commands from the primary slave
remote controller takes priority of aircraft movements (control sticks and gimbal dial). The
secondary slave remote controller only works if the primary slave remote controller is not
being operated for more than two seconds, whereas the primary slave remote controller
can always override it to regain control. The two remote controllers follow the same priority
for other commands.
If the Goggles RE are powered off or disconnected from the aircraft for more than 30
seconds during ight, the Goggles RE's corresponding slave remote controller will replace
it to control the aircraft. Note that there is still no live view on the DJI GO 4 app connected
to the slave remote controller.
Goggles RE (secondary)
√ Live View
√ Intelligent Flight Mode
×
Head Tracking
Goggles RE
(primary)
√ Live View
√ Head Tracking
√ Intelligent Flight
Mode
Remote
Controller
(primary slave)
Remote Controller
(secondary slave)
+2 s
Can't switch ight
modes.
No live view, only
support settings.
No live view,
only support
settings.
5. Press the Link button on the Mavic Pro. Once linked, the linking status indicator will turn solid
green.
6. Select “Connect Remote Controller” and conrm in Goggles RE.
7. Power on the secondary slave remote controller and connect it with the mobile device.
8. Launch the DJI GO 4 app and enter the camera view. Press
, then select “Remote Controller
Linking > Secondary Remote Controller,” for successful linking in a few seconds.
Multiuser Mode
Multiuser Mode is suitable for dual (or more) aircraft operator control. In this mode, the Goggles RE
operators with a slave remote controller can view the environment in real-time FPV for more intuitive
control. Please note that only the Goggles RE will display live view and that the primary Goggles RE
only support head tracking.
