SPECS

MAVIC MINI

Aircraft

 Takeoff Weight

[1]

 249 g

 Dimensions

 Folded: 140×82×57 mm (L×W×H)

Unfolded: 160×202×55 mm (L×W×H)

Unfolded (with propellers): 245×290×55 mm (L×W×H)

 Diagonal Distance

 213 mm

 Max Ascent Speed

 4 m/s (S Mode)

2 m/s (P Mode)

1.5 m/s (C Mode)

 Max Descent Speed

 3 m/s (S Mode)

1.8 m/s (P Mode)

1 m/s (C Mode)

 Max Speed (near sea level, no wind)

 13 m/s (S Mode)

8 m/s (P Mode)

4 m/s (C Mode)

 Max Service Ceiling Above Sea Level

 3000 m

 Max Flight Time

Summary of content (8 pages)

PAGE 1
SPECS MAVIC MINI Aircraft  Takeoff Weight [1]   249 g Dimensions   Folded: 140×82×57 mm (L×W×H) Unfolded: 160×202×55 mm (L×W×H) Unfolded (with propellers): 245×290×55 mm (L×W×H) Diagonal Distance   213 mm Max Ascent Speed   4 m/s (S Mode) 2 m/s (P Mode) 1.5 m/s (C Mode) Max Descent Speed   3 m/s (S Mode) 1.
PAGE 2
  30 minutes (measured while flying at 14 kph in windless conditions) Max Wind Speed Resistance   8 m/s (Scale 4) Max Tilt Angle   20°(C Mode) Max Angular Velocity   30°(S Mode) 20°(P Mode) 150°/s (S Mode) 130°/s (P Mode) 30°/s (C Mode) Operating Temperature Range   0°to 40°C (32°to 104°F) Operating Frequency   Model MT1SS5: 5.725-5.850 GHz Model MT1SD25: 2.400-2.4835 GHz, 5.725-5.850 GHz Transmission Power (EIRP)   Model MT1SS5 5.
PAGE 3
 Controllable Range   Tilt: -90°to 0°(default setting) -90°to +20°(extended) Stabilization   3-axis (tilt, roll, pan) Max Control Speed (tilt)   120°/s Angular Vibration Range  ±0.01° Sensing System  Downward   Operating Range: 0.5-10 m Operating Environment  Non-reflective, discernable surfaces Diffuse reflectivity (>20%) Adequate lighting (lux>15) Camera  Sensor  1/2.3” CMOS Effective Pixels: 12 MP Lens    FOV: 83° 35 mm Format Equivalent: 24 mm Aperture: f/2.
PAGE 4
 100-1600 (Auto) 100-3200 (Manual) Shutter Speed   Electronic Shutter: 4-1/8000s Still Image Size   4:3: 4000×3000 16:9: 4000×2250 Still Photography Modes   Single shot Interval: 2/3/5/7/10/15/20/30/60 s Video Resolution   2.7 K: 2720×1530 25/30 p FHD: 1920×1080 25/30/50/60 p Max Video Bitrate   40 Mbps Supported File System  FAT32（≤32 GB） exFAT（>32 GB）  Photo Format   JPEG Video Format  MP4 (H.
PAGE 5
 2.4 GHz: 2000 m (MIC/CE) 5.8 GHz: 500 m (CE) Operating Temperature Range   0°to 40°C (32°to 104°F) Transmission Power (EIRP)   Model MR1SS5 5.8 GHz: <30 dBm (FCC); <28 dBm (SRRC) Model MR1SD25 2.4 GHz: <19 dBm (MIC/CE) 5.8 GHz: <14 dBm (CE) Battery Capacity   2600 mAh Operating Current/Voltage   1200 mA 3.6 V (Android) 700 mA 3.6 V (iOS) Supported Mobile Device Size   Max length: 160 mm Max thickness: 6.5-8.
PAGE 6
 Output   12V 1.5 A / 9V 2A / 5V 3A Rated Power  18 W Intelligent Flight Battery  Capacity   2400 mAh Voltage   7.2 V Max Charging Voltage   8.4 V Battery Type   Li-ion 2S Energy   17.28 Wh Net Weight   100 g Charging Temperature Range   5°to 40°C (41°to 104°F) Max Charging Power  24 W Intelligent Flight Battery (1100 mAh)  Capacity   1100 mAh Voltage   7.6 V Max Charging Voltage   8.
PAGE 7
  LiPo 2S Energy   8.36 Wh Net Weight   50 g Charging Temperature Range   5°to 40°C (41°to 104°F) Max Charging Power  18 W APP  Name   DJI Fly Required Operating System  iOS v10.0 or later Android v6.0 or later Supported SD Cards  Supported SD Cards   UHS-I Speed Class 3 or above is required. A list of reccomended microSD cards can be found below.
PAGE 8
EXCERIA M303 V30 A1, Netac Pro V30 A1 256 GB: SanDisk Extreme V30 A1 Footnotes  Footnotes  1. Aircraft takeoff weight (includes battery and propellers). Registration not required in some countries and regions. Check local rules and regulations before use.These specs have been determined through tests conducted with the latest firmware. Firmware updates can enhance performance, so updating to the latest firmware is highly recommended.
