EA DIPS082
Technische Änderung vorbehalten. Wir übernehmen keine Haftung für Druckfehler und Applikationsbeispiele.
PINBELEGUNG
BEFEHLSTABELLE
Instruction
Code
Description
Execute
Time
(max.)
RS
R/W
DB
7
DB
6
DB
5
DB
4
DB
3
DB
2
DB
1
DB
0
Clear Display 0 0 0 0 0 0 0 0 0 1
Clears all display and returns the cursor
to the home position (Address 0).
1.64ms
Cursor At Home 0 0 0 0 0 0 0 0 1 *
Returns the Cursor to the home
position (Address 0). Also returns the
display being shifted to the original
position. DD RAM contents remain
unchanged.
1.64ms
Entry Mode Set 0 0 0 0 0 0 0 1 I/D S
Sets the Cursor move direction and
specifies or not to shift the display.
These operation are performed during
data write and read.
40µs
Display On/Off
Control
0 0 0 0 0 0 1 D C B
Sets ON/OFF of all display (D) cursor
ON/OFF (C), and blink of cursor position
character (B).
40µs
Cursor / Display Shift 0 0 0 0 0 1
S/C R/L
* *
Moves the Cursor and shifts the display
without changing DD RAM contents.
40µs
Function Set 0 0 0 0 1 DL N F * *
Sets interface data length (DL) number
of display lines (N) and character font
(F).
40µs
CG RAM Address Set 0 0 0 1 ACG
Sets the CG RAM address. CG RAM
data is sent and received after this
setting.
40µs
DD RAM Address Set 0 0 1 ADD
Sets the DD RAM address. DD RAM
data is sent and received after this
setting.
40µs
Busy Flag / Address
Read
0 1 BF AC
Reads Busy flag (BF) indicating internal
operation is being performed and reads
address counter contents.
-
CG RAM / DD RAM
Data write
1 0 Write Data
Writes data into DD RAM or CG RAM
40µs
CG RAM / DD RAM
Data Read
1 1 Read Data
Reads data from DD RAM or CG RAM
40µs
Pin Symbol Level Funktion Pin Symbol Level Funktion
1 VSS L Stromversorgung 0V (GND) 8 D1 H / L Display Data
2 VDD H Stromversorgung +5V 9 D2 H / L Display Data
3 VEE - Kontrastspg. (ca. 0,3V / 1,2V) 10 D3 H / L Display Data
4 RS H / L Umschaltung Befehl / Daten 11 D4 (D0) H / L Display Data
5 R/W H / L H=Read, L=Write 12 D5 (D1) H / L Display Data
6 E H Enable (fallende Flanke) 13 D6 (D2) H / L Display Data
7 D0 H / L Display Data / Anode LED-Bel. 14 D7 (D3) H / L Display Data, MSB
LED-BELEUCHTUNG
Das Display ist unter der Bestellbezeichnung EA DIPS082-HNLED auch mit einer integrierten
LED-Hintergrundbeleuchtung lieferbar. Der typ. Stromverbrauch liegt dann bei 50mA (max. 80mA). Die
Beleuchtung ist permanent eingeschaltet.
Durch folgende Modifikation kann die Beleuchtung auch extern steuer- und regelbar gestaltet werden:
Dazu muss der Vorwiderstandes R5 ausgelötet und die Lötbrücke LB2 geschlossen werden. Dann
kann am Pin 7 (D0) über eine positive Spannung die LED-Beleuchtung gesteuert werden. In diesem
Fall muss das Display dann im 4-Bit Mode angesteuert werden! Der LED-Vorwiderstand ist extern
anzubringen (R
Ext.
= 0,8V / I
LED
)
