Operation Manual

7 Working with the hand-held steam cleaner

7.3 Using special nozzles

1. Fit the pinpoint nozzle as described, ZChapter 7.2, “At-

taching the pinpoint nozzle”.

2. If the cleaning effect of the jet of steam alone is not suf-

ficient for your cleaning task, select a special nozzle:

 The wire brush (Fig. 26/A) is used to remove particu-

larly stubborn soiling from non-delicate surfaces.

 The plastic brushes(Fig. 26/B, large and small) are

used to remove heavy soiling from scratch-resistant surfac-

es.

 The crevice brush (Fig. 26/C) works best for removing

dirt from between tiles and grooves.

 The jet nozzle (Fig. 27/A) is recommended if the steam

jet has to be highly concentrated like for the pinpoint jet noz-

zle.

 The spatula attachment (Fig. 27/B) is used to scrape

dirt from smooth surfaces which are not sensitive to

scratching.

 The 2in1 combo attachment (Fig. 28/A) is used to

squeegee previously steamed glass surfaces. To do so, fol-

low the instructions in ZChapter 7.4, “Steam-cleaning

glass surfaces”.

 The 2in1 combo attachment (Fig. 28/B) with cotton

cover is used to freshen up upholstery and clothing. To do

so, follow the instructions in ZChapter 7.5, “Freshening up

upholstery and clothing”.

3. Slide the respective special nozzle onto the pinpoint jet

nozzle.

4. Secure the respective special nozzle by turning it 90° in

the direction of the arrow.

NOTE:

All special nozzles can only be fitted to the previ-

ously installed pinpoint nozzle. All special nozzles are

attached in the same way.

NOTE:

By turning is in the opposite direction you can release the

respective special nozzle again.

90°
