11 Technical Data
1 Type and order code
BWP 30H BWP 30HLW
2Design
Without additional internal heat
exchanger
With additional internal heat
exchanger
2.1 Casing Foil cladding Foil cladding
2.2 Colour White, similar to RAL 9003 White, similar to RAL 9003
2.3 Nominal cylinder volume l 300 290
2.4 Cylinder material
Enamelled steel according to DIN
4753
Enamelled steel according to DIN
4753
2.5 Nominal cylinder pressure bar 10 10
3Model
3.1 Dimensions height (max.) x cross-section (max.) mm 1695 x 700 1695 x 700
3.2 Weight kg Approx. 110 Approx. 125
3.3 Electrical connection (plug-in - lead length approx. 2.7 m) 1/N/PE ~ 230 V, 50 Hz 1/N/PE ~ 230 V, 50 Hz
3.4 Fuse A 16 16
3.5 Refrigerant / total filling weight - / kg R134a / 1.0 R134a / 1.0
4 Operating conditions
4.1 Selectable water temperature (heat pump operation
±1.5 K
) °C
23 to 60 23 to 60
4.2 Air temperature operating range of heat pumps
1
°C
1. Temperatures below 8 °C (+/- 1.5 °C) will cause the heating element to switch on and the heat pump module to switch off automatically; the dead-band value of the controller is 3 K
8 to 35 8 to 35
4.3 Sound pressure level
2
dB(A)
2. At a distance of 1 m (free-standing installation without inlet and outlet ducting or without 90° pipe bends on the outlet side)
53 53
4.4 Air flow during heating-only heat pump operation m
3
/h
450 450
4.5 External compression Pa 100 100
4.6 Maximum length of pipe that can be used for the air duct m 10 10
5 Connections
5.1 Diameter of the air duct connection (inlet/outlet) mm 160 160
5.2 Transfer area of the internal tube heat exchanger m
2
-1,45
5.3 Sensor pipe D
internal
(for sensor – heat exchanger operation) mm
- 12
5.4 Water connections - cold water / hot water R 1“ R 1“
5.5 Circulation pipe R 3/4" R 3/4"
5.6 Heat exchanger flow / return flow -R 1“
6 Performance data
6.1 Power consumption supplementary electrical heating W 1500 1500
6.2 Mean power consumption
3
at 60 °C W
3. Heating up of the nominal volume from 15 °C to 60 °C at an air inlet temperature of 15 °C and 70 % relat. humidity
615 615
6.3 Mean heat output
4
at 45 °C W
4. Heating up of the nominal volume from 15 °C to 45 °C at an air inlet temperature of 15 °C and 70 % relat. humidity
1870 1870
6.4 COP
(t)
according to EN 255 at 45 °C -
3,5 3,5
6.5 Stand-by energy consumption at 45 °C/24h (W) 47 47
6.6 Max. mixed water volume at 40 °C V
max.
l
300 290
6.7 Heating-up period from 15 °C to 60 °Ct
h
h
9,1 9,1
