Display
TM
for 5 seconds.
B. Flame E󰀨ects
Turns the ame e󰀨ect On and O󰀨.
→ Activated by pressing the
but-
ton on the remote.
C. Heat ON/OFF
Turns the heater On and O󰀨.
→ Activated by pressing the
but-
ton on the unit or the remote.
• Indicated by the
icon and the
intake temperature being displayed
on the Floating Display
TM
, for 5
seconds before turning off.
!
NOTE: After the heater is
switched o󰀨, there is a 60 second
fan delay, where the fan will con-
tinue running before turning o󰀨.
!
NOTE: The unit can be oper-
ated in Heat Only Mode. When
the unit is only running with the
heater, the
icon will continu-
Figure 13
WARNING: This electric rebox
must be properly installed before it
is used.
The unit can be controlled by either
the manual controls which are located
on the upper right of the replace or
the remote (Figure 13 & 14).
The replace is supplied with an IR
multifunction remote control.
!
NOTE: To operate correctly, the
remote control must be pointed
towards the Floating Display
TM
.
A. Standby
Turns the unit On and O󰀨.
→ Activated by pressing the Standby
button on the remote or the unit.
• The unit will turn on with the same
functions that it was set to when
it was turned O󰀨 and the intake
temperature will be indicated on
the Floating Display
TM
.
!
NOTE: When any button is
pressed the intake temperature
will be displayed on the Floating
Operation
A C D E
F
Floating
Display
TM
Figure 14
A
D
B
C
E
G
H
F
