How to Guide

11
Fireplace Installation
4. Mark the 3 mounting screw
locations, on the wall, ensuring
that the wall bracket stays level.
(Figure 5)
5. In locations where the screws are
being installed only into drywall,
install the supplied wall anchors
before installing the screw (predrill
if required).
6. Secure the wall bracket to the wall
using the supplied 1½ in. (3.8 cm)
mounting screws and washers
into the wall and/or wall anchors.
7. Install the bottom support bracket
to the wall centered with the
wall mounting bracket, using the
appropriate mounting hardware,
13 ¾" (350 mm) below the wall
mounting bracket. (Figure 5)
Figure 6
Figure 5
Wall Mounting
Bracket
Bottom Support
Bracket
8. Remove the center back screw
from the bottom of the replace.
(Figure 6)
9. Hang the replace from the
bracket.
10. Install the removed screw through
the bottom support bracket into
the replace.
11. Refer to Front Glass Installa-
tion section for nal installation
procedures.
