DF-800/1600 User Manual 25
cursor to SYSTEM 02 and double clicks the left button of mouse to switch
current PC port to PC port 2.
Press “ Ins” key or click the right button of mouse for editing PC name.
Press “ Esc” key to cancel editing PC name without any change or Enter” ”
key to complete the new PC name.
5.3.3 PORT SEARCH
Figure 5-7. Port Search
OSD Function Key Description
Enter Start Port Search
F1 Go to Main Menu
F2 Console off
F3 Back
Esc Exit
Table 5-5. OSD Function Key
Search the computer by port name. Enter “*” will show the all the port.
5.3.4 USER SECURITY
At USER SERCURITY of OSD can setup one SUPERVISOR and eight
ADMINISTRATORS all with 8 digits name and password.
P O R T S E A R C H X
E N T E R N A M E ： _ _ _ _ _ _ _ _ _ _
