SROM Mini-Debugger Command Set 3–13
User Commands
* Write-only registers whose values are obtained from a copy placed in PALtemp registers
1and 2 when they were written with the dc command. Therefore, changing these internal
CPU registers overwrites the saved contents of the general-purpose CPU registers 1 and 2
(also stored in PALtemp 1 and 2), affecting the output of the pr command.
Example
In the following example, output on a DS21064 CPU is displayed:
SROM> dc ! Enable machine checks and CRD interrupts
IPR> abox
D> 6
*ABOX 00000000.00000006
SROM> ec
Abox 00000000.00000006
Icsr 00000000.00ff0000
PalB 00000000.00000000
ExAd 00000000.00200cac
DcSt 00000000.00000003
Hirr 00000000.00000000
Hier 00000000.00001890
BCtl 000007f8.00000000
BiSt 00000000.00001040
BiAd 00000000.01ffd010
Syn 00000000.00000000
FiAd 00000000.01ffd014
21066
Abox* ABOX_CTL Abox control
Icsr ICSR Ibox control and status
PalB PAL_BASE PAL base address
Table 3–2 CPU Register Names for the dc Command
(Sheet 2 of 2)
Mini-debugger Name CPU Register Name Description
