Getting Started 2–45
Onboard Machine Check Handler
SROM> dm ! RTC.
A> 8580006e20
D> 0600
SROM> dm ! Select the interrupt register.
A> 8580006e00
D> 70
SROM> dm ! Configure to interrupt as IRQ8.
A> 8580006e20
D> 0800
SROM> dm ! Activate the RTC.
A> 8580006e00
D> 30
SROM> dm
A> 8580006e20
D> 0100
SROM> dm ! Put SMC in run mode by writing
A> 8580006e00
! 0xAA to address 0x370.
D> AA
! The RTC is now ready to be used.
2.12 Onboard Machine Check Handler
The onboard machine check handler is useful in debugging certain memory faults.
You must set bit [1] of the ABOX_CTL register to enable machine checks. For
21164-based boards, machine checks are always enabled. When a machine check is
encountered, as it might be in a read, the machine check handler prints the following
message followed by the SROM> prompt:
MCHK
Abox 00000000.00000002
Icsr 00000000.00ff0000
PalB 00000000.00000000
ExAd 00000000.00200cb4
DcSt 00000000.0000000b
Hirr 00000000.00000000
Hier 00000000.00001890
BCtl 000007f8.00000000
BiSt 00000000.000010c1
BiAd 00000001.e0000018
