Getting Started 2–41
Sample Session on the AlphaPC 164LX
SROM> dm ! Set MCR (memory control register).
A> 8750000000
D> 3a1401
SROM> dm ! Set RTR again to force a
A> 8750000300
! refresh after the MCR has been set.
D> 750
! Set the memory bank registers for two banks of DIMMs totalling
! 128MB.
SROM> dm
! Set memory BBAR0
A> 8750000600
! (base address register 0).
D> 0
SROM> dm ! Set memory BBAR1.
A> 8750000640
D> 100
SROM> dm ! Set memory BTR0
A> 8750000a00
! (base timing register 0).
D> 22
SROM> dm ! Set memory BTR1.
A> 8750000a40
D> 22
SROM> dm ! Set memory BCR0
A> 8750000800
! (base configuration register 0).
D> 28
! Write once with the bank disabled.
SROM> dm ! Set memory BCR1.
A> 8750000840
D> 28
SROM> dm ! Set memory BCR0.
A> 8750000800
! Write a second time enabling the banks.
D> 29
SROM> dm ! Set memory BCR1.
A> 8750000840
D> 29
