2–36 Getting Started
Sample Session on the AlphaPC 164
SROM> mt ! Perform a memory test.
A> 0
A> 4000000
SROM> wa
Wrt Addr OFF
SROM> sb
! Set base address for PCI configuration
A> 8700000000
! space.
00000087.00000000
BaseAddr ON
SROM> dm
! Reset the ISA bus.
A> 809a0
! Assert the reset signal.
D> 4800
SROM> dm ! Deassert the reset signal.
A> 809a0
D> 4000
SROM> dm ! Set UBCSA register to allow access to
A> 809c0
! lbios and xbios.
D> c00000
SROM> dm ! Set UBCSB register to allow access to
A> 809e0
! configuration jumpers (address 0x801-2)
D> ff000000
SROM> em ! Read SIO identification registers.
A> 80000
! The value shown is the Intel ID for
00000087.00080000:04848086 ! this part.
SROM> ba
00000087.00000000
BaseAddr OFF
SROM> dm
! Write out to the LEDs post-card. You
A> 8580001000
! should see an “F0” on it.
D> f0
