Getting Started 2–35
Sample Session on the AlphaPC 164
SROM> ec ! Make sure changes are reflected here.
BCtl 00000004.c4008051
BCfg 00000000.01f21691
Icsr 000000c2.4e000000
PalB 00000000.00000000
ExAd 284c8800.00080000
Ipl 00000000.0000000e
Int 00000000.00000015
Isr 00000000.00200000
IcPE 00000000.00000000
DcMd 00000000.00000001
DcPE 00000000.00000000
SROM> dm
! Enable CACK of Bcache Victims.
A> 8740000600
D> 8
SROM> dm
! Enable all 3 sets in the secondary cache
A> fffff000a8
! and leave at 64-byte blocks.
D> f000
SROM> fm ! Fill memory to obtain good ECC.
A> 0
A> 4000000 ! Total memory size in board.
D> 12345678
! Clear any possible errors in the CPU and memory controller.
SROM> em
A> fffff000e8
! SC_STAT register.
000000ff.fff000e8: 0001a86b
SROM> em
A> fffff00168
! EI_STAT register.
000000ff.fff00168: f1ffffff
SROM> em
A> 8740008200
! CIA_ERROR register.
00000087.40008200: 00000000
SROM> wa
Wrt Addr ON
