2–32 Getting Started
Sample Session on the AlphaPC 164
SROM> ec ! Note changes to BCtl and BCfg.
BCtl 00000000.00008040
BCfg 00000000.01f21bb0
Icsr 000000c2.4e000000
PalB 00000000.00000000
ExAd 00000000.00000000
Ipl 00000000.0000001e
Int 00000000.00000015
Isr 00000000.00200000
IcPE 00000000.00000000
DcMd 00000000.00000000
DcPE 00000000.00000000
SROM> dm
! Set the CIA_CTRL register.
A> 8740000100
D> 2104c0f5
SROM> dm ! Set the PCI timer register.
A> 87400000C0
D> ff00
! Set the CIA_CACK_EN register. Note that the
! Bcache victim bit has been set to 0 since the
! Bcache has been disabled.
SROM> dm
A> 8740000600
D> 0
SROM> sb ! Set base address for memory controller.
A> 8750000000
00000087.50000000
BaseAddr ON
! Set the refresh rate, Bcache size to 0 (disabled) and memory
! width to 256-bits (all 8 SIMM slots populated). If 128-bit
! width is being used, clear the low bit of this register.
SROM> dm
A> 0 ! Memory configuration register.
D> 2001fe01
