Getting Started 2–25
Sample Session on the EB164
SROM> fm
A> 0
> 4000000
! Total memory size.
D> 0
! This may take a few seconds.
SROM> dc
! Turn on the DCache.
IPR> dcmd
D> 1
*DCMD 00000000.00000001
SROM> dc
! Turn on the Bcache.
IPR> bctl
D> 8051
*BCTL 00000000.00008051
! The BCFG value shown is for a 266MHz CPU, with 2MB, 10ns Bcache.
! For other configurations, use maximum read and write speeds allowed.
SROM> dc
IPR> bcfg
D> 1e22772
*BCFG 00000000.01e22772
SROM> ec
BCtl 00000000.00008051
BCfg 00000000.01e22772
.... ! The rest of the registers were omitted here.
DcMd 00000000.00000001
.... ! The rest of the registers were omitted here.
SROM> dm
! Tell memory controller the size of Bcache (2MB).
A> 8750000000
D> 1fe21
SROM> dm ! Enable CACK of Bcache Victims.
A> 8740000600
D> 8
SROM> dm
! Enable all 3 sets in the secondary cache and
A> fffff000a8
! leave at 64-byte blocks.
D> f000
