2–8 Getting Started
Sample Session on the EB64
2.6.1 EB64 Sample Log File
The following sample log file initializes the EB64.
! Sample EB64 Initialization Log file.
V00001c01
SROM> dc
! Deposit to the BIU_CTL register
IPR> bctl
! and turn off the BCache.
D> e2000e444
*BCTL 0000000e.2000e444
SROM> ec
Abox 00000000.00000000
Icsr 00000000.00bf0000
PalB 00000000.00000000
ExAd 00004000.00000002
DcSt 00000000.0000000f
Hirr 00000000.00000000
Hier 00000000.00000000
BCtl 0000000e.2000e444 ! This shows BIU_CTL has been changed.
BiSt 00000000.00003240
BiAd 00000000.28210b88
Syn 00000000.00000000
FiAd 00000000.28210b88
SROM> dm
! Turn off the BCache, set DRAM size to
A>200000000
! 2Mx36 (32MB of memory) and 1 cycle CAS
D> 2c40000
! slip in EB64 system register.
SROM> em
! Some bits in the system register are
A> 200000000
! Read-Only so the examine may show a
00000002.00000000: aec400c3 ! different value than written.
SROM> sb
! Set the base address to be used in
A> 2c0000000
! initializing clocks, timers and
00000002.c0000000 ! memory refresh.
BaseAddr ON
SROM> dm
! Initialize the rest of the system.
A> 7600
D> 1
SROM> dm
A> 7680
D> bf00
SROM> dm
A> 7600
D> 6
