SITE CODES 5-8
> > > >
Site Codes 5-8
(7063/7063A, 7073/7073A, 693/793 only)
Enter site codes 5-8 (left to right separated by
> sign). Press the Select key below the > sign to
add, delete, or change the site code and press
COMMAND. Site code range is 0-999.
NO OF USER CODE
DIGITS: 5
Number of User Code Digits
(7063/7063A, 7073/7073A, 693/793 only)
The keypad recognizes user codes from four to six
digits in length. Press any Select key to enter the
user code digit length being used by the panel.
Default is 5.
When searching the bit string from the reader for
the user code, the digits are identied and read
from left to right. When a four-digit user code is
selected only the rst four digits of the string are
read.
The table below identies the panel types, the
required operating modes for the arming/disarming
feature, and the appropriate code conguration
(4, 5, or 6 digits) for each panel.
Operation
XR500 Series/
XR2500F
XRSuper6
XR20/
XR40
XR200 XR200-485
Arms H/A
Disarms H/A
—
—
4-digit
4-digit
4-digit
4-digit
4-digit
4-digit
—
—
Arms A/P
Disarms A/P
—
—
—
4-digit
—
4-digit
—
5-digit
—
—
Arms Area(s)
Disarms Area(s)
—
4, 5, or 6-digits
—
—
—
4-digit*
—
5-digit*
—
5-digit
* During entry delay only. — Not available on this panel type.
Note: XR200-485 and XR200 Command Processor™ Panels recognize a user code with a
maximum of ve digits.
As of March 2005, XR500 Series and XR2500F Command Processor™ Panels recognize a
user code with a maximum of six digits.
