User's Manual

DIGITAL CONTROL INCORPORATED
DigiTrak Falcon

F2

Operator’s Manual 63
Appendix A: System Specifications
Power Requirements
Device (Model Number)
Operational Voltage
Operational Current
DigiTrak Falcon F2 Receiver
(FAR2)
14.4 V
300 mA max
DigiTrak SE NiMH Battery
Charger (SBC)
Input 100–240 VAC
Output 25 V (nominal)
350 mA max
700 mA max
DigiTrak SE NiMH Battery Pack
(SBP)
14.4 V (nominal)
2.0 Ah
29 Wh max
DigiTrak F Series Battery
Charger (FBC)
Input 10–28 V
Output 19.2 V
5.0 A max
1.8 A max
DigiTrak F Series Lithium-Ion
Battery Pack (FBP)
14.4 V (nominal)
4.5 Ah
65 Wh max
DigiTrak Falcon F2 Transmitter
(BTW)
1.2–4.2V
1.75 A max
Environmental Requirements
Device
Relative Humidity
Operating Temperature
DigiTrak Falcon F2 Receiver
(FAR2) and Remote Display
with NiMH Battery Pack
with Lithium Battery Pack
<90%
-10 to 65° C
-20 to 60° C
DigiTrak BTW Transmitter
<100%
-20 to 104° C
DigiTrak Falcon Compact
Display (FCD)
with NiMH Battery Pack
with Li-Ion Battery Pack
<90%
-10 to 65° C
-20 to 60° C
DigiTrak SE NiMH Battery
Charger (SBC)
<90%
0 to 40° C
DigiTrak SE NiMH Battery Pack
(SBP)
<99% for <10° C
<95% for 10–35° C
<75% for 35–65° C
-10 to 65° C
DigiTrak F Series Battery
Charger (FBC)
<99% for 0–10° C
<95% for 10–35° C
0 to 35° C
DigiTrak F Series Lithium-Ion
Battery Pack (FBP)
<99% for <10° C
<95% for 10–35° C
<75% for 35–60° C
-20 to 60° C
System working altitude: up to 2000 m.
