Data Sheet

10/3/2018 JTAG-SMT3-NC Reference Manual [Reference.Digilentinc]
https://reference.digilentinc.com/reference/programmers/jtag-smt3/reference-manual 10/16
JTAG-SMT3-NC () JTAG-SMT2 JTAG-SMT2-NC ()JTAG-SMT3-NC () JTAG-SMT2 JTAG-SMT2-NC ()
Max Speed 30 MHz () 30 MHz () 30 MHz ()
Voltage Range 1.8V – 5V 1.8V – 5V 1.8V – 5V
Xilinx Native Support ISE 14.1+
Vivado 2014.1
ISE 14.1+
Vivado 2013.1+
ISE 14.1+
Vivado 2013.1+
Xilinx Plug-in Support ISE 13.1+ ISE 13.1+ ISE 13.1+
Digilent Adept Support YES YES YES
PC Interface USB USB USB
Onboard USB Connector YES YES NO
Host Board Connector Interface 18-pad SMT 11-pad SMT 13-pad SMT
4-Wire JTAG YES YES YES
2-Wire JTAG NO YES YES
Zynq-7000 PS_SRST Support YES YES YES
SPI Support NO YES YES
Independent UART Channel YES NO NO
Pin Number Pin Name Pin Number Pin Name
1 GND () 10 TCK
2 VREF_UART 11 TDO
3 CTS 12 TDI
4 RTS 13 TMS
5 RXD 14 GND ()
6 TXD 15 VDD
7 GND () 16 USB_DM
8 VREF_JTAG 17 USB_DP
9 PS_SRST_B 18 VBUS_DETECT
Note: Pin 9 on the silkscreen of the JTAG SMT3-NC () may be incorrectly labeled as GND () rather than the correct label of PS_SRST_B.
Pinout Table
