Instruction manual

52
Advanced Recording Mode
Alarm Setup Mode
• PARAMETER MODE - Contains the
general recording parameters for each
camera
• SCHEDULE MODE - Contains the
schedule recording settings for each
camera.
NOTE: Audio Recording ONLY works on
Channels 1~4.
Alarm Parameter Mode
Parameters for each camera are set by hour
using the Time Interval bar.
Press the ENTER key to select the Interval
Bar, and navigate using the arrow keys.
Select an Hour (highlighted in Green), and
press ENTER again to open the Camera
Settings for the selected hour.
• Size - Sets the video capture size for
each camera to 352x240, 704x240 or
704x480.
• FPS - Sets the Frames Per Second for
recording for each channel. Each
channel can be set to 1, 2, 3, 7, 15 or
30 Frames per second (real time video
capture) from a shared pool of 120 FPS.
• Quality - Sets the video recording quality
to Low, Standard, High or Highest.
• Audio - Turns audio recording ON/OFF
Select the OK button to apply the changes.
Once settings have been adjusted for the
hour, the changed time block will be
displayed in yellow on the Time Interval bar.
Time Interval Bar
Selected Hour
Camera Setting Controls
Changed Time Block
