6 Message Reference
Note: Attempting to activate TDM timeslots that are not present on the underlying TDM (e.g., using a
bitmap of 0xfffefffe when the TDM is configured as T1) may NOT result in the rejection of the
configuration message.
• mgmt_id
ID of management module for status updates.
• upper_stream_id
Upper layer (layer 3) stream identifier – this is a logical identifier from the upper layer for the cell stream
and is not board specific.
6.5.3 ATM_MSG_END_STREAM – Remove ATM Cell Stream Configuration
Synopsis
Message used to remove an active ATM cell stream.
Format
Description
Sent by the user to stop processing on a previously configured ATM cell stream.
Once successfully processed, the link may be reconfigured. The confirmation message (if requested)
indicates success with a status value of 0.
6.5.4 ATM_MSG_R_STREAM_STATS – Per ATM Cell Stream Statistics
Synopsis
Message used to retrieved (and reset) per cell stream statistics.
Format
MESSAGE HEADER
FIELD NAME MEANING
type ATM_MSG_END_STREAM
id Cell Stream ID
src Sending module ID
dst ATM_module_ID
rsp_req Used to request a confirmation.
hclass 0
status SDE Message status code
err_info 0
len 0
MESSAGE HEADER
FIELD NAME MEANING
type ATM_MSG_R_STREAM_STATS (0x6263)
id Cell Stream ID
src Sending module ID
dst ATM_module_ID
rsp_req Used to request a confirmation.
hclass 0
status Used to reset the statistics
err_info 0
len 36
