56
6 Message Reference
6.2.6 MGT_MSG_L1_END – Layer 1 Configuration End
Synopsis
Message sent to a board to remove an existing layer 1 link that was previously configured by sending an
MGT_MSG_L1_CONFIG message.
Format
Parameters
The MGT_MSG_L1_END message includes the following parameters:
• l1_resource_id
Layer 1 (logical) resource identifier.
6.2.7 MGT_MSG_NTP_CONFIG – Network Time Configuration
Synopsis
Configures network-specific time parameters.
Format
Description
This message is issued to the signaling processor MGMT module by the host application to enable or disable
timestamping, specify the poll interval and communicate host NTP server module ID.
MESSAGE HEADER
Field Name Meaning
type MGT_MSG_L1_END (0x7f18)
id 0
src Sending module's module ID
dst MGMT_module_ID
rsp_req Used to request a confirmation.
hclass 0
status 0
err_info 0
len 4
PARAMETER AREA
Offset Size Name
0 2 Reserved. Must be set to 0.
2 2 l1_resource_id
MESSAGE HEADER
Field Name Meaning
type MGT_MSG_NTP_CONFIG (0x7f0d)
id 0
src Sending module's module ID
dst MGMT_TASK_ID
rsp_req Used to request a confirmation
class 0
status 0
err_info 0
len 8
PARAMETER AREA
Offset Size Name
0 2 enable
2 2 poll_interval
4 4 ntp_management_id
