51
Dialogic
®
DSI SS7MD Programmer’s Manual Issue 3
• run_mode
The protocols to be run. The following table shows the permitted values and their meaning.
The following combinations of link types are available to the user.
Note: When using multiple link types on the same board, the run mode indicates to the board the
predominant link type.
Note: It is only possible to activate protocols that have been licensed to run on the board by use of a
suitable host licenses.
Value Run Mode Protocols Selected to Run on the Board
34 LSL MTP2 Low Speed Links
35 HSL MTP2 High Speed Links
36 ATM ATM links
37 IMA Inverse Multiplexed ATM links
Run
Mode
LSL Links HSL Links ATM Links IMA Links
LSL Y Y Y
HSL Y Y Y
ATM Y Y Y
IMA Y Y
