140
7 Configuration Command Reference
7.4.3 ATM_TIMER – Configure Timers for Q.SAAL Links
Synopsis
Override the default timer values for ATM Links.
Syntax
ATM_TIMER <reserved> <timer_id> <value>
Example
ATM_TIMER 0 T1 10
Parameters
The ATM_TIMER command includes the following parameters:
• <reserved>
This parameter is reserved for future use and should be set to zero.
• <timer_id>
The identifier of the timer to be changed. It should be set to one of the following values: CC,
KEEP_ALIVE, NO_RESP, POLL, IDLE, T1, T2, T3.
• <value>
The timer value in milliseconds. Any timers not configured continue to be set to the values shown in the
following table.
Timer ID Default Value (ms) Range (min - max)
CC 1,500 15 - 2,500
KEEP_ALIVE 300 15 - 2,500
NO_RESP 1,500 100 - 10,000
POLL 100 20 - 600
IDLE 100 20 - 600
T1 5,000 1,000 - 20,000
T2 120,000 10,000 - 300,000
T3 10 1 - 30
