121
Dialogic
®
DSI SS7MD Programmer’s Manual Issue 3
• <build_out>
The build out type. The following table shows the permitted values and their meanings.
Value Description Valid For
0 Setting for E1 devices liu_type = 5
1 T1/J1 default (short haul)
liu_type = 4
8 T1/J1 long haul LBO (-0 dB)
9 T1/J1 long haul LBO (-7.5 dB)
10 T1/J1 long haul LBO (-15 dB)
12 T1/J1 long haul LBO (-22.5 dB)
