116
6 Message Reference
0x6214 SS7_MSG_R_STATS Read Link Statistics Request
0x6215 SS7_MSG_R_STATE Read Link State Request
0x6263 ATM_MSG_R_STREAM_STATS Per ATM Cell Stream Statistics
0x6266 ATM_MSG_R_AAL_LINK_STATS Per Monitored Link Statistics
0x6f0d MGT_MSG_R_BRDINFO Read Board Info Request
0x7200 SS7_MSG_RESET Q.SAAL Module Reset Request
0x7203 SS7_MSG_CONFIG MTP2 Link Configuration Request
0x7260 ATM_MSG_CONFIG Configure ATM
0x7261 ATM_MSG_CFG_STREAM ATM Cell Stream Configuration
0x7262 ATM_MSG_END_STREAM Remove ATM Cell Stream Configuration
0x7264 ATM_MSG_AAL_CFG_MON_LINK Configure AAL Monitor Link
0x7265 ATM_MSG_AAL_END_LINK Remove AAL Link
0x7267 QSL_MSG_CFG_LINK Configure Q.SAAL Link
0x7268 QSL_MSG_CFG_TIMERS Configure Timers per Q.SAAL Link
0x7269 QSL_MSG_END_LINK Remove Q.SAAL Link
0x7680 SSD_MSG_RESET SSD Reset Request
0x7681 SSD_MSG_RST_BOARD Board Reset Request
0x7689 SSD_MSG_BOARD_INFO Board Information Request
0x7e00 MVD_MSG_RESETSWX Reset Switch Request
0x7e17 MVD_MSG_SC_LISTEN Cross Connect Switch Listen Request
0x7e18 MVD_MSG_SC_DRIVE_LIU LIU Switch Initialization
0x7e19 MVD_MSG_SC_MULTI_CONNECT Multiple Connect Request
0x7e1f MVD_MSG_SC_CONNECT Connect Request
0x7e17 MVD_MSG_SC_LISTEN Cross Connect Switch Listen Request
0x7e18 MVD_MSG_SC_DRIVE_LIU LIU Switch Initialization
0x7e34 LIU_MSG_CONFIG LIU Configuration Request
0x7e35 LIU_MSG_CONTROL LIU Control Request
0x7f0d MGT_MSG_NTP_CONFIG Network Time Configuration
0x7f10 MGT_MSG_CONFIG0 Board Configuration Request
0x7f17 MGT_MSG_L1_CONFIG Layer 1 Configuration Request
0x7f18 MGT_MSG_L1_END Layer 1 Configuration End
0x8f01 API_MSG_RX_IND Received Data Indication
0x8f0f API_MSG_RX_INDT Timestamped Incoming Signaling Unit Indication
0xcf00 API_MSG_TX_REQ MTP2 Transmission Request
Table 7. Message Summary (Continued)
Message Type Mnemonic Description
