115
Dialogic
®
DSI SS7MD Programmer’s Manual Issue 3
6.9 Message Summary Table
The following table lists, by message type, all the messages described in this manual.
Table 7. Message Summary
Message Type Mnemonic Description
0x0003 MGT_MSG_TRACE_EV Trace Event Indication
0x0008 MGT_MSG_EVENT_IND Error Indication
0x0201 MGT_MSG_SS7_STATE Link State Indication
0x0202 MGT_MSG_SS7_EVENT MTP2 Q.791 Event Indication
0x026a ATM_MSG_STREAM_STATE ATM Stream Status Indication
0x026b ATM_MSG_LINK_STATE AAL Link Status Indication
0x026c MGT_MSG_QSL_EVENT Q.SAAL "Q.791 style" Event Indication
0x06a0 SSD_MSG_STATE_IND Board Status Indication
0x0e01 MVD_MSG_LIU_STATUS LIU Status Indication
0x0f09 API_MSG_CNF_IND Configuration Completion Status Indication
0x0f1d MGT_MSG_NTP_SYNC Timestamping Resynchronization Indication
0x1213 Confirmation of SS7_MSG_TRACE_MASK
0x1e37 Confirmation of LIU_MSG_R_CONFIG
0x1e38 Confirmation of LIU_MSG_R_CONTROL
0x2214 Confirmation of SS7_MSG_R_STATS
0x2215 Confirmation of SS7_MSG_R_STATE
0x1e39 Confirmation of LIU_MSG_R_STATE
0x3200 Confirmation of SS7_MSG_RESET
0x3203 Confirmation of SS7_MSG_CONFIG
0x3267 Confirmation of QSL_MSG_CFG_LINK
0x3268 Confirmation of QSL_MSG_CFG_TIMERS
0x3269 Confirmation of QSL_MSG_END_LINK
0x3680 Confirmation of SSD_MSG_RESET
0x3681 Confirmation of SSD_MSG_RST_BOARD
0x3689 SSD_MSG_BOARD_INFO Board Information Request
0x3e00 Confirmation of MVD_MSG_RESETSWX
0x3e17 Confirmation of MVD_MSG_SC_LISTEN
0x3e18 Confirmation of MVD_MSG_SC_DRIVE_LIU
0x3e1f Confirmation of MVD_MSG_SC_CONNECT
0x3e34 Confirmation of LIU_MSG_CONFIG
0x3e35 Confirmation of LIU_MSG_CONTROL
0x3f0d Confirmation of MGT_MSG_NTP_CONFIG
0x3f10 Confirmation of MGT_MSG_CONFIG0
0x3f17 Confirmation of MGT_MSG_L1_CONFIG
0x318 Confirmation of MGT_MSG_L1_END
0x5213 SS7_MSG_TRACE_MASK Set Trace Mask Request
0x5e36 LIU_MSG_R_STATS LIU Read Statistics Request
0x5e37 LIU_MSG_R_CONFIG LIU Read Configuration Request
0x5e38 LIU_MSG_R_CONTROL
LIU Read Control Request
0x5e39 LIU_MSG_R_STATE LIU Read State Request
0x6111 GEN_MSG_MOD_IDENT Module Identification Request
0x6136 DVR_MSG_R_L1_STATS Link Statistics Request
