101
Dialogic
®
DSI SS7MD Programmer’s Manual Issue 3
6.6.11 Primitives issued to MTP3-b
The following primitives are supported by the Q.SAAL module. For message definitions refer to Dialogic®
SS7 Protocols MTP2 Programmer's Manual.
MTP2 Primitive Description NNI Primitive Equivalent
API_MSG_RX_IND Received Data Indication AAL-RECEIVED_MESSAGE
SS7_MSG_IN_SVC In Service Indication AAL-IN_SERVICE
SS7_MSG_OUT_SVC Out of Service Indication AAL-OUT_OF_SERVICE
SS7_MSG_RXD_BSNT BSNT Indication - extended version AAL-BSNT
API_MSG_RTVD_MSG Retrieved Message Indication AAL-RETRIEVED_MESSAGES
SS7_MSG_RTVL_COMPL Retrieval Complete Indication AAL-RETRIEVAL_COMPLETE
SS7_MSG_RTVL_NOT_POS Retrieval Failure Indication AAL-BSNT_ NOT_RETRIEVABLE
SS7_MSG_LINK_CONG Link Congested Indication AAL-LINK_CONGESTED
SS7_MSG_LINK_UNCONG Link Congestion Cleared Indication AAL-LINK_CONGESTION_CEASED
SS7_MSG_FLUSH_ACK Flush Acknowledgement N/A
SS7_MSG_REM_PR_OUT RPO Indication N/A
SS7_MSG_REM_PR_OK RPO Cleared Indication N/A
