3 Introduction
The DA14580 QFN48 antenna module is based on the Dialog Semiconductor DA14580 Bluetooth
®
Smart SoC. It is a stand-alone system consisting of the DA14580 SoC in a QFN48 package, 16 MHz
and 32 kHz crystals, a DC/DC converter and a printed antenna. The module was successfully tested
for FCC/IC certification and CE marking. This document presents the module system, its technical
specifications, physical dimensions and test results.
4 System overview
Features 4.1
■ Highly integrated Dialog Semiconductor DA14580 Bluetooth
®
Smart SoC
■ Module can be used stand-alone or as a data pump in a system with an external processor
■ Antenna module in buck configuration certified according to FCC/IC and CE marking
■ Module meets all Bluetooth Smart requirements
■ No external crystal or additional passive components required for module operation
■ Access to processor via JTAG, SPI, UART or I
2
C
■ 32 GPIOs available on module at a 1.27 mm pitch, suitable for keyboard designs
■ Operating voltage: 2.4 V to 3.6 V, suitable for operation from a single cell coin battery
■ On-board printed inverted F-type antenna
■ Up to 0 dBm RF transmitted power
■ Receiver sensitivity: better than -92 dBm
■ Supply current:
□ Transmit/Receive mode: typ. 5 mA peak current @ 3.0 V
□ Sleep mode: typ. 2 µA average current
■ 17.89 mm x 25.4 mm, 38 pins, two layer PCBA
Electrical characteristics 4.2
Table 1: QFN48 antenna module characteristics`
Parameter Description Conditions Min Typ Max Unit
V
BAT
battery supply voltage 2.4 3.0 3.3 V
f
OPER
operating frequency 2400 2483.5 MHz
P
O
output power
conducted; V
BAT
= 3 V,
T
A
= 25 °C
0 dBm
P
SENS
sensitivity level
V
BAT
= 3 V, T
A
= 25 °C
-92 dBm
I
BAT_TX
battery supply current
transmit mode; peak value ;
V
BAT
= 3 V, T
A
= 25 °C
5 mA
I
BAT_SLP
battery supply current sleep mode; average value;
V
BAT
= 3 V, T
A
= 25 °C
2
µA
