Table 9: Bill of Materials
No Qty Description Part Ref Value Part Number Package Manufacturer
1 1
CAP CERM
1.0uF 16V X7R
0603
C1
1.0 µF
0603YC105K AT2A 0603 AVX Corporation
2 2
CAP MLCC,
0204, 1UF, 6.3V,
20%, X5R
C2 C3
1.0 µF
GRM155R70
G105KA12D
0402
Murata
Electronics
3 2
RES 0.0 OHM
1/16W 5% 0402
SMD
CR1 R4
0 Ω
CRCW04020
000Z0ED
0402 Vishay/Dale
4 1
FILTER
CHI0.5ohm 0.4A
0603
FB1 BLM18AG102 SN1D 0603
Murata
Electronics
5 1
INDUCTOR
Power 2.2uH,
500mA, 400MHz
L1
2.2 µH
BRL1608T 2R2M 0603 Taiyo Yuden
6 1
RESISTOR,
THICK FILM, 0
OHM, 250mW,
5%
R1
0 Ω
RC1206JR- 070RL 1206 YAGEO
7 1
INDUCTOR RF,
0402, 5.1NH,
±0.3NH, 0.26ohm
R5 5.1 nH L-07C5N1 SV6T 0402
JOHANSON
TECHNOLOGY
8 1
RF INDUCTOR
0402 3.9NH,
±0.3NH 0.22ohm
R6 3.9 nH L-07C3N9 SV6T 0402
Johanson
Technology Inc
9 1
RESISTOR,
0201, 0R0
R8
0 Ω
CRCW02010
000Z0ED
0201
VISHAY
DRALORIC
10 1
DA14580
Bluetooth Low
Energy SOC –
QFN48
U1 DA14580-00AT1
QFN48, 6x
6 x 0.9mm
DIALOG SEMI
11 1
CRYSTAL
16.000MHZ 10PF
SMT
Y1 16 MHz 7M-16.000 MEEQ-T
xtal4p
25x20
TXC
Not Populated
1 1 Inductor L2 NM 0402
2 1 Resistor R3
0 Ω
0603
3 1
crystal
32.768KHZ,
±20ppm, 7PF
Y2
32.768
kHz
ABS06-32.768KHz-
7-T
2x1.2mm
Abracon
Corporation
4 1 Resistor R2
0 Ω
CRCW0402 0000
Z0ED
0402 Vishay/Dale
