Data Sheet

TB6612FNG
Target characteristics
PD - Ta
0.00
0.50
1.00
1.50
0 50 100 150
Ta (℃)
(w)
①
②
①IC単体θj-a=160℃/W
②基板実装時
PCB面積 50×50×1.6mm
Cu箔面積≧40%
③基板実装時
PCB面積 76.2×114.3×1.6mm
Cu箔面積≧30%
③
①IC only θj – a = 160°C/W
②
In boarding
PCB area 50 mm×50 mm×1.6 mm
Cu area ≥ 40%
③
In boarding
PCB area 76.2 mm×114.3 mm×1.6 mm
Cu area ≥ 30%
Power dissipation P
D
P
D
- Ta
Ta = 25°C, IC only
1 ch driving
2 ch driving
Iout - Duty
0.0
0.5
1.0
1.5
2.0
2.5
0% 20% 40% 60% 80% 100%
Duty
(A)
2ch動作時
1ch動作時
Ta=25℃,IC単体
Output current
I
OUT
I
OUT
- Duty
Dual-channel operation
Single-channel operation
Ta = 25°C, IC only
2014-10-01
6
