MCP2515
REGISTER 10-2: CANSTAT – CAN STATUS REGISTER
(ADDRESS: XEh)
R-1 R-0 R-0 U-0 R-0 R-0 R-0 U-0
OPMOD2 OPMOD1 OPMOD0 — ICOD2 ICOD1 ICOD0 —
bit 7 bit 0
bit 7-5 OPMOD: Operation Mode bits <2:0>
000 = Device is in the Normal operation mode
001 = Device is in Sleep mode
010 = Device is in Loopback mode
011 = Device is in Listen-only mode
100 = Device is in Configuration mode
bit 4 Unimplemented: Read as ‘0’
bit 3-1 ICOD: Interrupt Flag Code bits <2:0>
000 = No Interrupt
001 = Error Interrupt
010 = Wake-up Interrupt
011 = TXB0 Interrupt
100 = TXB1 Interrupt
101 = TXB2 Interrupt
110 = RXB0 Interrupt
111 = RXB1 Interrupt
bit 0 Unimplemented: Read as ‘0’
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown
