Use and Care Manual

ENGLISH
1
English (original instructions)
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.

(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.

WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.
WARNING: To reduce the risk of injury, read the
instructionmanual.
If you have any questions or comments about this or
any
DeWALT
tool, call us toll free at:
1-800-4-
DeWALT
(1-800-433-9258).
1
Trigger switch lock-off button
2
Trigger switch
3
Battery pack
4
Depth adjustment lever (Fig.H)
5
Shoe
6
Lower blade guard retracting lever
7
Lower blade guard
8
Blade clamping screw
9
Kerf indicator
10
Bevel adjustment lever
11
Blade lock button
12
Auxiliary handle
13
Battery release button
14
Blade wrench (Fig.H)
15
Worklight
Fig. A
1 2
1211
15
957
8
6
13
10
3
