Operation Manual

17
ENGLISH
Congratulations!
You have chosen a D E WALT tool. Years of
experience, thorough product development and
innovation make D
E WALT one of the most reliable
partners for professional power tool users.
Technical Data
D51180
Type 1
P
s min
(min. operating pressure) bar 4.8
P
s max
(max. operating pressure) bar 8.5
Air consumption per shot l 0.2
(at 6.9 bar)
Actuating mode contact
actuating
Fasteners
type bulk
length mm 19 - 89
max. head diameter mm 10
Weight kg 1.2
L
PA
(sound pressure) dB(A) 92
K
PA
(sound pressure uncertainty) dB(A) 1.5
L
WA
(sound power) dB(A) 101
K
WA
(sound power uncertainty) dB(A) 2.5
Vibration total values (triax vector sum) determined according to
EN 60745:
Vibration emission value a
h
a
h
= m/s² 5.4
1
Uncertainty K = m/s² 1.5
1)
This value is a tool-related characteristic value
and does not represent the infl uence to the
hand-arm-system when using the tool.
The infl uence to the hand-arm-system when
using the tool will for example depend on the
gripping force, the contact pressure force,
the working direction, the adjustment of energy
supply, the workpiece and the workpiece support.
Defi nitions: Safety Guidelines
The definitions below describe the level of severity for
each signal word. Please read the manual and pay
attention to these symbols.
DANGER: Indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING: Indicates a potentially
hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION: Indicates a potentially
hazardous situation which, if not avoided,
may result in minor or moderate
injury.
NOTICE: Indicates a practice not
related to personal injury which, if
not avoided, may result in property
damage.
Denotes risk of electric shock.
Denotes risk of fire.
EC-Declaration of Conformity
MACHINERY DIRECTIVE
D51180
DEWALT declares that these products described
under “technical data” are in compliance with:
2006/42/EC, EN 792-13, EN 12549, ISO 8662-11.
These products also comply with Directive 2004/108/
EC. For more information, please contact DEWALT
at the following address or refer to the back of the
manual.
The undersigned is responsible for compilation of the
technical file and makes this declaration on behalf of
DEWALT.
Horst Grossmann
Vice President Engineering and Product Development
D
EWALT, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
31.12.2009
NAILER
D51180
