NOTE: Do not turn the

power off until the oven

temperature is below

100EC (212EF).

NOTE: EF is selected in the tune

mode.

Programming Examples and Outline

The following examples show a step by step procedure for

programming Protocol in the Manual, Timer and Program

modes. Example 1 covers the Manual mode and example 2

covers the Timer mode. A detailed outline covers the Pro-

gram mode with a programming worksheet and examples 3-5

following the outline.

Example 1 - Manual Mode

Control the process at 250EF.

Manual Mode Example

Key DISPLAY Description

Manual

Heater On

Start

Stop

Heater Off

MANUAL

Hi-Limit

HL 200

HL 275

SETPOINT

180 75

250 75

READY

250 75

READY

Select Manual mode

Enter the high limit temperature

High limit temperature currently set at 200EF

Increase high limit temperature to 275EF

Enter the setpoint

Setpoint at 180EF, actual oven temperature at 75EF

Increase setpoint to 250EF

Protocol is ready to run Manual mode

Heater relay initiated, heater ready for power

Setpoint = 250EF, actual oven temperature = 75EF

Stop Manual mode

Heater relay LED is off, heater secured off
