LBB Series Oven Owner’s Manual Version 15 LBB SERIES OVEN OWNER’S MANUAL Copyright © 2012 by Despatch Industries. ABOUT THIS MANUAL 1 C-188 PN 146230 VERSION 15 8/2012 All rights reserved.
LBB Series Oven Owner’s Manual Version 15 ABOUT THIS MANUAL 2 Revision History Revision C Date Author D E F G H I J K L 12 13 14 15 3/2011 9/2011 6/2012 8/2012 Livingston Livingston Livingston Livingston Description Updated electrical drawings in DRAWINGS AND SPARE PARTS LISTS section. Corrections.
LBB Series Oven Owner’s Manual Version 15 ABOUT THIS MANUAL 3 Table of Contents 1. 2. 3. 4. 5. About This Manual ............................................................................................................. 7 1.1. Important User Information ..................................................................................... 7 1.2. Manufacturer & Service .......................................................................................... 8 1.3. Organization of this Manual ......
ABOUT THIS MANUAL 4 6. 7. 8. LBB Series Oven Owner’s Manual Version 15 5.3.1. Start Oven .......................................................................................................... 31 5.4. Working with the Control Instrument ................................................................... 33 5.4.1. Change Setpoint................................................................................................. 33 5.4.2. Control Instrument Parameter Programming Mode .....................
LBB Series Oven Owner’s Manual Version 15 ABOUT THIS MANUAL 5 8.3.8. LBB2-18-1 ......................................................................................................... 64 8.3.9. LBB2-27-1 ......................................................................................................... 65 8.4. Electrical Schematics............................................................................................. 65 Figures Figure 1. Disconnect Switch....................................
ABOUT THIS MANUAL 6 LBB Series Oven Owner’s Manual Version 15 Table 6. High Limit instrument Setup Parameters. ....................................................................... 39 Table 7. Common Technical Issues and Remedies. ...................................................................... 54 Table 8. LBB1-23A-1 Parts. .......................................................................................................... 61 Table 9. LBB1-23B-1 Parts. .......................................
LAC Series Oven Owner’s Manual Version 15 1. ABOUT THIS MANUAL 7 About This Manual 1.1. Important User Information Copyright © 2012 by Despatch Industries. All rights reserved. No part of the contents of this manual may be reproduced, copied, or transmitted in any form or by any means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and retrieval systems without the written permission of the publisher, unless it is for the purchaser's personal use.
LAC Series Oven Owner’s Manual Version 15 ABOUT THIS MANUAL 8 Danger! Only fully-trained and qualified personnel should setup and maintain this equipment. Improper setup and operation of this equipment could cause an explosion that may result in equipment damage, personal injury or possible death. The information in this document is not intended to cover all possible conditions and situations that might occur.
LAC Series Oven Owner’s Manual Version 15 ABOUT THIS MANUAL 9 Danger! Failure to heed warnings in this instruction manual and on the oven could result in personal injury, property damage or death. 1.4. Conventions This icon signifies information that describes an unsafe condition that may result in death, serious injury, or damage to the equipment.
LAC Series Oven Owner’s Manual Version 15 ABOUT THIS MANUAL 10 1.5. Specifications 1.5.1. Dimensions LBB Model No. Chamber Size in (cm) W 0 Capacity 3 feet (liters) D H Overall Size in (cm) W D H Shelves Maximum Chamber Provided Number of Doors on Shelf Shelf Centers Positions in (cm) 1-23 18 (46) 18 (46) 12 (30) 2.3 (65) 24 (61) 23 (58) 26 (66) 2 on 2” (5.1) 5 1 1-43 24 (61) 14 (36) 22 (56) 4.3 (122) 30 (76) 19 (48) 36 (91) 2 on 2” (5.
LAC Series Oven Owner’s Manual Version 15 1.5.2. ABOUT THIS MANUAL 11 Capacities LBB Model Number Capacity 1-23 1-43 1-69 2-12 2-18 2-27 Maximum Load Lbs (Kg) 200 (91) 200 (91) 400 (181) 600 (272) 600 (272) 600 (272) Maximum Shelf Load Lbs (Kgs) 50 (23) 50 (23) 200 (91) * 200* (91) 200* (91) 200* (91) Exhaust Capacity CFM (LPS) 1 (0.5) 2 (0.9) 3 (1.4) 12 (5.7) 14 (6.6) 14 (6.6) Maximum load capacity not valid on ovens with the “control panel located on bottom” option.
LAC Series Oven Owner’s Manual Version 15 ABOUT THIS MANUAL 12 Volts Amps Hertz Phase Heater KW Cord and Plug LBB 1-23A 120 11.6 50/60 1 1.2 Included, 15 Amp LBB 1-23B 240 5.8 50/60 1 1.2 Included, 15 Amp LBB 1-43A 120 15.3 50/60 1 1.6 Included, 20 Amp LBB 1-43B 240 7.7 50/60 1 1.6 Included, 15 Amp † 120 21.6 50/60 1 2.4 None, Hardwired † 240 10.8 50/60 1 2.4 None, Hardwired † 240 16.6 50/60 1 3.6 None, Hardwired LBB 2-18 † 240 16.7 50/60 1 3.
LAC Series Oven Owner’s Manual Version 15 1.5.4.
LAC Series Oven Owner’s Manual Version 15 ABOUT THIS MANUAL 14 1.5.5. LBB Series Oven Operating Conditions The LBB Series oven is for indoor use. Table 1 provides the operating conditions. Table 1. Operating/Environmental Conditions (For indoor use). Item Description Operating Temperature ‡ 18°C to 40°C (64.4°F to 104°F) Relative Humidity 70% non‐condensing Maximum Altitude 2,000 meters (6,600 feet) ‡ Fluctuations in temperature can occur at elevated ambient temperature values.
LBB Series Oven Owner’s Manual Version 15 2. Safety 2.1. Safety Information Do not work on the LBB Series oven without reading and understanding this section which contains important information and warnings. Ignoring these warnings can result in death, serious injury or damage to the machine and product. 2.1.1. Lockout Carefully follow the established Lock Out Tag Out policies of your company in all cases.
LBB Series Oven Owner’s Manual Version 15 SAFETY 16 2.2. Provisions for Lifting and Carrying Caution! Do not tilt oven while lifting. Do not lift oven using the door handle to prevent damage to the oven and/or personnel involved. Caution! Do not risk injury when lifting equipment. Take proper precautions when lifting, carrying or otherwise maintaining heavy items. How to lift the different sizes of ovens: LBB1-12 & LBB1-43: Four people lift oven’s lower corners and place on wheeled transport pallet.
LBB Series Oven Owner’s Manual Version 15 2.3. Maintenance Only qualified and trained personnel should perform maintenance or repair. Warning! Do not place this oven in an environment harmful to electrical components. Placing this oven in an environment detrimental to electrical components (for example, environments where carbon fibers, coal dust or similar contaminants may be present) may result in component failure. Contact Despatch for options available to help prevent such failures. 2.4.
LBB Series Oven Owner’s Manual Version 15 SAFETY 18 Warning! Do not place this oven in an environment harmful to electrical components. Placing this oven in an environment detrimental to electrical components (for example, environments where carbon fibers, coal dust or similar contaminants may be present) may result in component failure. Do not use liquids in the oven. Do not set product or liquids on top of the oven.
LBB Series Oven Owner’s Manual Version 15 2.7. Disconnecting Devices 2.7.1. Power Requirements Despatch recommends the LBB Series Ovens have unobstructed access to a dedicated power source. 2.7.2. Use a power stabilizer if voltage fluctuation is greater than ±10% nominal voltage fluctuation. Disconnecting Hard-Wired Units LBB permanently-connected (hard-wired) ovens include models LBB1-69, LBB2-12, LBB2-18 and LBB2-27.
LBB Series Oven Owner’s Manual Version 15 SAFETY 20 2.7.4. Disconnecting Units with Optional Disconnect Switch The LBB Series oven has an optional Disconnect Switch (Figure 1). This Disconnect Switch is located on the front of the oven and connected to the load break switch behind the panel that disconnects or connects power from the main line. When a risk of personal injury or damage to the LBB Series oven exists, turn off the Disconnect Switch. This shuts off all electrical power to the oven.
LBB Series Oven Owner’s Manual Version 15 3. THEORY OF OPERATION 21 Theory of Operation 3.1. The LBB Series Oven The Despatch LBB Series ovens (Figure 2) effectively distribute heat with a processing time among the fastest of any lab oven its class. LBB Series ovens are effectively used in testing, preheating, sterilizing, drying, aging and curing as well as other production applications.
LBB Series Oven Owner’s Manual Version 15 THEORY OF OPERATION 22 Warning! Do not remove the hat bracket as it distributes exhaust air and protects the exhaust opening from being completely covered. 3.1.1. Oven Theory The LBB Series forced circulating oven uses fan to circulate air through the chamber. A circulating oven is much more efficient and uniform oven than a gravity-convection oven due to the constant air movement.
LBB Series Oven Owner’s Manual Version 15 THEORY OF OPERATION 23 Table 2. Control Instrument Explanations. Display Main (PV) Display Key SP OUT AL1–2 Description Typically displays actual oven temperature. Press SET/ENT to display setpoint. Displays parameter code and value. Press to switch between PV and SP displays. Enter data using or . Press repeatedly to switches through parameter displays.
LBB Series Oven Owner’s Manual Version 15 THEORY OF OPERATION 24 3.3.1. High Limit Instrument The LBB Series oven is equipped with a High Limit instrument (Figure 6). The High Limit instrument protects the oven or product by discontinuing the heating process when the High Limit is exceeded. Set the High Limit instrument to a temperature 10°C - 14°C higher than the control instrument setpoint, or to a temperature that should not be exceeded in the process.
LBB Series Oven Owner’s Manual Version 15 4. ASSEMBLY & SETUP 25 Assembly & Setup Assembly and Setup provides directions for unpacking and installing your Despatch LBB Series oven. 4.1. Unpack & Inspect the LBB Series Oven Remove all packing materials and thoroughly inspect the oven for any damage that might have occurred during shipment.
LBB Series Oven Owner’s Manual Version 15 ASSEMBLY & SETUP 26 4.2.2. Set-up Procedure Warning! All grounding and safety equipment must be in compliance with applicable codes, ordinances and accepted safe practices. Warning! Do not use the oven in wet, corrosive or explosive atmospheres unless this oven is specifically designed for a special atmosphere. 1. Place oven on bench top or optional cabinet base. a. Ensure a minimum of two (2) inches (5.
LBB Series Oven Owner’s Manual Version 15 4.2.3. ASSEMBLY & SETUP 27 Wiring & Power Connections Read the Model LBB nameplate (top of oven or top of control area under the door) for proper power requirements before proceeding with wiring and power connections (Figure 7). Danger! All grounding and safety equipment must be in compliance with applicable codes, ordinances and accepted safe practices. Models LBB1-23A, -23B, -43A and -43B come equipped with an appropriate plug and cord.
LBB Series Oven Owner’s Manual Version 15 ASSEMBLY & SETUP 28 To wire the LBB Series oven (for units requiring hardwiring): 1. Remove the top cover for access to the connector block (Figure 8). Figure 8. LBB Series Oven with Top Removed. 2. Run the wire through the rear access hole (Figure 9) and connect the appropriate wires at the connector block (Figure 10). Figure 9. Wiring Access through Rear of Oven. Figure 10. Close-up of Connector Block. Copyright © 2012 by Despatch Industries.
LBB Series Oven Owner’s Manual Version 15 5. OPERATION 29 Operation Users and operators of this oven must comply with operating procedures and training of operating personnel as required by the Occupational Safety and Health Act (OSHA) of 1970, Section 5 and relevant safety standards, and other safety rules and regulations of state and local governments. Refer to the relevant safety standards in OSHA and National Fire Protection Association (NFPA), Section 86 of 1990.
LBB Series Oven Owner’s Manual Version 15 OPERATION 30 The two shelves are designed to be pulled out about halfway without tipping. Do not overload the shelves (Refer to Support Capacity listed in Section 1.5.3). Distribute the workload evenly so airflow is not restricted. Do not overfill your oven. The workload should not take up more than two-thirds of any dimension of the inside cavity.
LBB Series Oven Owner’s Manual Version 15 OPERATION 31 For sample heating, close vent when no ventilation is required 5.3. Operating Procedure Warning! Do not use flammable solvent or other flammable material in this oven. Do not process closed containers of any substance or liquid in this oven because they may explode under heat. 5.3.1. For fastest oven heat-up time, close the exhaust vent. After the desired temperature is reached, adjust the vent as needed. Start Oven 1.
LBB Series Oven Owner’s Manual Version 15 OPERATION 32 a. When the process value on the Control instrument reaches setpoint, OUT cycles ON and OFF to maintain the temperature setpoint. b. OUT lights when the control calls for heat. 6. Turn HEATER OFF after the heating cycle is complete. 7. Do not turn the fan OFF until the oven chamber temperature is below 100◦C (212◦F). Figure 11. LBB Series Oven Control Panel. Figure 12. Adjust Damper to Set Exhaust Vent by rotating the outer component.
LBB Series Oven Owner’s Manual Version 15 OPERATION 33 5.4. Working with the Control Instrument Danger! Failure to heed warnings in this instruction manual and on the oven could result in personal injury, property damage or death. The LBB Series oven is factory tested and the controls have been factory-set for normal operating conditions. In most applications it is not necessary to alter the oven’s settings, except for Setpoint.
LBB Series Oven Owner’s Manual Version 15 OPERATION 34 5.4.2. Control Instrument Parameter Programming Mode Warning! Changing program parameters alters the function of the Control. Proceed carefully and fully understand each parameter before changing that parameter. Control instrument parameters are set through the Operating and Set-up modes. In most applications, it is not necessary to alter the oven settings.
LBB Series Oven Owner’s Manual Version 15 Ct Cycle Time FL Input Filter bS PV Bias (Offset) LoC Key Lock nr Manual Reset HyS Hysteresis 5.4.2.2. Expressed in seconds, value shows total time for one ON/OFF cycle of the controller output during the proportional action Expressed in seconds. Use this function when the PV may fluctuate greatly (for example, when an input signal contains noise) Expressed in degrees, from –199 to 999.
LBB Series Oven Owner’s Manual Version 15 OPERATION 36 Despatch recommends leaving the SC feature OFF OFF SC Super Function Direct/Reverse Action Direct/Reverse action. This value is set for 0 (reverse action). 0 dr PV/SP Display Priority of PV/SP display. This parameter either displays the PV (process variable) or SP (setpoint). 0 = process variable 1 = setpoint 0 dSP 5.4.3.
LBB Series Oven Owner’s Manual Version 15 9. 10. 11. OPERATION 37 Repeat steps 7-8 for SPL . Enter a value of 32. Press and hold the for three (3) seconds to return to the operation mode. a. The control now reads in degrees Fahrenheit. b. Enter the desired setpoint. Refer to Table 5 to change tuning parameters, if necessary. 5.4.4. To change from Fahrenheit to Centigrade, repeat the steps in Section 5.4.
LBB Series Oven Owner’s Manual Version 15 OPERATION 38 5.4.5. Set the High Limit Danger! Failure to heed warnings in this instruction manual and on the oven could result in personal injury, property damage or death. The oven has been factory-tested with the High Limit instrument factory-preset for normal operating conditions. In most applications, it will not be necessary to alter the oven's settings, except for the Setpoint.
LBB Series Oven Owner’s Manual Version 15 5.4.6. OPERATION 39 High Limit Instrument Parameter Setup Mode Warning! Changing program parameters alters the function of the High Limit. Proceed carefully and fully understand each parameter before changing that parameter. Set High Limit instrument parameters using the Operating and Set-up modes (Section 5.4.2.1). In most applications, it is not necessary to alter the oven settings.
LBB Series Oven Owner’s Manual Version 15 OPERATION 40 SHif PV shift value (offset). Moves the display temperature to the oven temperature Filt PV filter. out1 Output 1 function. If the process value is unstable to read, increasing this value steadies the input signal. Function of the output. Must be set to Hi. for High Limit control. o1.Hy Output 1 hysteresis value. Amount of degrees the temperature must be below the setpoint temperature before the High Limit can be reset HSP.
LBB Series Oven Owner’s Manual Version 15 OPERATION 41 7. Press to return the High Limit instrument to normal mode. 8. The High Limit instrument has been changed, enter the desired setpoint. 5.5. Working with Optional Protocol 3 Controller Operating Modes Refer to the Protocol 3 Controller Owner’s Manual for specifics on working with the Protocol 3 controller. Copyright © 2012 by Despatch Industries. All rights reserved.
LBB Series Oven Owner’s Manual Version 15 MAINTENANCE 42 6. Maintenance Danger! Failure to heed warnings in this instruction manual and on the oven could result in personal injury, property damage or death. Danger! Do not attempt any service on this oven before opening the main power disconnect switch. Warning! Do not place this oven in an environment harmful to electrical components.
LBB Series Oven Owner’s Manual Version 15 MAINTENANCE 43 Establish maintenance and checkup schedules. Do this promptly and follow the schedules faithfully. Careful operation and maintenance will be more than paid for in continuous, safe and economical operation. Maintain equipment in good repair. Make repairs immediately. Delays may be costly in added expense for labor and materials and in prolonged shut down. Practice safety. Make it a prime policy to know what you are doing before you do it.
LBB Series Oven Owner’s Manual Version 15 MAINTENANCE 44 6.3.2. Decontaminating the LBB Series Oven Warning! Do not decontaminate oven without first disconnecting power. Ensure adequate personal safety while decontaminating oven. Notice Before using any cleaning or decontamination method except those recommended by the manufacturer, users should check with the manufacturer that the proposed method will not damage the equipment. For best results, decontaminate the work zone daily. 1.
LBB Series Oven Owner’s Manual Version 15 MAINTENANCE 45 Test LBB Series oven functions regularly and carefully for best performance. Safety of personnel and maintenance of your equipment may depend on the proper operation of any of the temperature control functions. 6.4.1. Test Control Instrument 6.4.2.
LBB Series Oven Owner’s Manual Version 15 MAINTENANCE 46 Danger! Do not attempt any service on this oven before opening the main power disconnect switch. Tools needed: One-quarter (1/4) inch socket set Screwdriver T20 Torx bit driver 1. Disconnect power. 2. Remove four screws from the face of the control panel (Figure 13). Figure 13. Remove Control Panel to Access Control Instrument. 3. Slide the panel forward (Figure 14). Copyright © 2012 by Despatch Industries. All rights reserved.
LBB Series Oven Owner’s Manual Version 15 MAINTENANCE 47 Figure 14. Providing easy access to the Control instrument. 4. Remove wires from the old control instrument, carefully noting which wires connect to which terminals (Figure 15). High Limit Instrument Control Instrument Thermocouple wires Figure 15. Remove Old Control and High Limit Instruments and Wiring (Rear View). Copyright © 2012 by Despatch Industries. All rights reserved.
LBB Series Oven Owner’s Manual Version 15 MAINTENANCE 48 5. Move the Control instrument mounting bracket back and off (Figure 16). Control Instrument Mounting Bracket Figure 16. Prepare to remove control instrument by removing the mounting bracket. 6. 7. 8. 9. Remove old Control instrument from the panel. Install new Control instrument into the control panel. Secure instrument mounting bracket. Reattach wires to the new Control instrument. Double-check that the wires are connected correctly.
LBB Series Oven Owner’s Manual Version 15 6.5.2. MAINTENANCE 49 Replace High Limit Instrument Danger! Do not attempt any service on this oven before opening the main power disconnect switch. Tools needed: One-quarter (1/4) inch socket set Screwdriver 1. 2. 3. 4. T20 Torx bit driver Disconnect power. Remove four screws from the face of the control panel (Figure 13). Slide the panel forward (Figure 14).
LBB Series Oven Owner’s Manual Version 15 MAINTENANCE 50 Figure 19. Press and Hold Tabs to Remove High Limit Instrument. 8. Install new High Limit instrument into the control panel. 9. Replace mounting bracket. 10. Connect High Limit instrument connector plug to the circuit board (Figure 18). 11. Reattach thermocouple wires. Make sure that the wires are connected correctly. (Figure 15). See Figure 20 for correct High Limit instrument connections. 12. Replace control panel. Figure 20.
LBB Series Oven Owner’s Manual Version 15 MAINTENANCE 51 6.5.3. Replace (Optional) Protocol 3 Controller 6.5.4. Replace Heater Unit Refer to the Protocol 3 Owner’s Manual for instructions on replacing the Protocol 3 Controller. Danger! Do not attempt any service on this oven before opening the main power disconnect switch. Tools needed: 3/8 inch wrench One-quarter (1/4) inch socket set T20 Torx bit driver 1. Disconnect power. 2. Remove shelves (Figure 22). 3.
LBB Series Oven Owner’s Manual Version 15 MAINTENANCE 52 Figure 23. Typical Heating Element. 6.5.5. Replace Fan Motor Danger! Do not attempt any service on this oven before opening the main power disconnect switch. Tools needed: One-quarter (1/4) inch socket set 5/32 inch Allen wrench Screwdriver T20 Torx bit driver 1. Disconnect power. 2. Remove shelves (Figure 22). 3. Remove left and right side ducts a. Remove screws from each duct. b. Remove duct from oven. 4.
LBB Series Oven Owner’s Manual Version 15 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16. 17. 18. 19. 20. MAINTENANCE 53 a. Remove screws from the heater cover. b. Remove heater cover from the oven. Loosen setscrews (2) on fan wheel in middle of oven top. Access the fan wheel through the heater opening or by disconnecting and removing the heater assembly. Refer to Section 6.5.4 for information on removing the heater unit. Remove top cover to reveal fan motor (Figure 24). Remove fan motor a.
LBB Series Oven Owner’s Manual Version 15 MAINTENANCE 54 7. Troubleshooting Like any equipment operating over long periods of time, technical issues may arise. Table 7 lists the common technical issues, their causes and remedies. Table 7. Common Technical Issues and Remedies. Technical Issue Probably Cause Suggested Remedy/Next Step No power Check power source and/or oven and wall fuses. Burned out heater(s) Replace element (see Warranty statement, Section 8.1).
LBB Series Oven Owner’s Manual Version 15 Technical Issue TROUBLESHOOTING 55 Probably Cause Fan wheel has shifted or fallen. Suggested Remedy/Next Step Inspect the wheel. Reposition fan wheel within 0.25” from top of housing. Debris has fallen into fan through shaft collar. High Limit instrument set too low Inspect the wheel for damage. Remove debris. Oven will not control at Setpoint Control instrument malfunction Heater does not shut down until temp.
LBB Series Oven Owner’s Manual Version 15 APPENDICES 56 8. Appendices 8.1. Standard Products Warranty Copyright © 2012 by Despatch Industries. All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
LBB Series Oven Owner’s Manual Version 15 APPENDICES 57 8.2. Optional Equipment 8.2.1. Assemble Oven Stand 1. Install four rubber grommets into holes in the stand (Figure 25). a. For LBB1-69 stands, the rear grommets mount into the forward set of rear holes. b. On LBB2-12 stands the rear grommets mount into the set of holes closest to the rear of the stand. 2. Place the oven on top of the stand. The four embossed areas in the bottom of the oven should center in the grommets. 3.
LBB Series Oven Owner’s Manual Version 15 APPENDICES 58 8.2.2. Timer Option Use the timer option to count down in hours toward powering the heater OFF (Figure 26). When the timer is ON, the delayed contact remains closed allowing power to the heater. The range display increments from 0 and the Timing LED blinks slowly. When the preset value is reached and the timing cycle is complete, the Timing LED blinks rapidly and the delayed contact opens and shuts off the heater.
LBB Series Oven Owner’s Manual Version 15 8.2.2.2. APPENDICES 59 Configure the Timer Danger! Do not attempt any service on this oven before opening the main power disconnect switch. The timer is configured for XX.X hours (that is, two positions left of the decimal, one to the right) from our factory. The timer can be easily set up for different timing ranges. Follow these instructions to configure the timer: 1. Remove power from oven. 2. Remove top cover. 3. Remove socket from rear of timer. 4.
LBB Series Oven Owner’s Manual Version 15 APPENDICES 60 Reset the High Limit instrument whenever it has tripped. Reset the High Limit Instrument by allowing the oven chamber to cool slightly (or by setting the High Limit Instrument by . several degrees) and pushing Each oven schematic (Section 8.4) shows the wiring for this option. 8.2.5. Recorder Option The circular chart recorder uses and independent thermocouple to record the user’s process. Charts used are either 24 hour or 7 day.
LBB Series Oven Owner’s Manual Version 15 APPENDICES 61 8.3. Part Lists 8.3.1. LBB1-23A-1 Table 8. LBB1-23A-1 Parts. Part Number Quantity 144755 1 140097 2 057345 1 165051 1 144749 1 007818 1 145858 1 148048 1 008199 2 145828 2 007281 1 008333 1 006049 1 150131 1 123306 1 125562 1 8.3.2. Description Thermocouple Switch For Power And Heater Relay Heater SSR High Limit Despatch L91 Control - Des2000 Heater 1.2kw 120/240v Door Seal Door Pull Latch Ay Standard Shelf Fan Wheel Motor 00.
LBB Series Oven Owner’s Manual Version 15 APPENDICES 62 8.3.3. LBB1-43A-1 Table 10. LBB1-43A-1 Parts. Part Number Quantity 144755 1 140097 2 057345 1 165051 1 144749 1 054353 1 145920 1 148048 1 008199 2 146025 2 007281 1 008333 1 006049 1 150131 1 123306 1 144785 1 8.3.4. Description Thermocouple Switch For Power And Heater Relay Heater SSR High Limit - Despatch L91 Control - Des2000 Heater 1.6kw 120/240v Door Seal Door Pull Latch Ay Standard Shelf Fan Wheel Motor 00.
LBB Series Oven Owner’s Manual Version 15 8.3.5. LBB1-69A-1 Table 12. LBB1-69A-1 Parts. Part Number Quantity 144755 1 140097 2 057345 1 165051 1 144749 1 007819 1 145725 1 008057 3 148048 1 008199 2 146024 2 094717 2 007281 1 008333 1 006049 1 150131 1 123306 1 134923 1 8.3.6. APPENDICES 63 Description Thermocouple Switch For Power And Heater Relay Heater SSR High Limit - Despatch L91 Control - Des2000 Heater 2.
LBB Series Oven Owner’s Manual Version 15 APPENDICES 64 8.3.7. LBB2-12-1 Table 14. LBB2-12-1 Parts. Part Number Quantity 144755 1 140097 2 057345 1 165051 1 144749 1 007778 1 145773 1 008057 4 148048 1 008199 2 145779 2 146023 2 015876 1 145783 1 015229 1 150132 1 117172 2 124475 2 8.3.8. Description Thermocouple Switch For Power And Heater Relay Heater SSR High Limit Despatch L91 Control - Des2000 Heater 3.
LBB Series Oven Owner’s Manual Version 15 8.3.9. APPENDICES 65 LBB2-27-1 Table 16. LBB2-27-1 Parts. Part Number Quantity 144755 1 140097 2 057345 1 165051 1 144749 1 007819 2 145814 1 008057 4 148048 1 008199 2 016472 2 105497 2 015876 1 145783 1 015229 1 150132 1 117172 2 134923 2 Description Thermocouple Switch For Power And Heater Relay Heater SSR High Limit - Despatch L91 Control - Des2000 Heater 2.
LBB Series Oven Owner’s Manual Version 15 APPENDICES 66 Figure 28. LBB1-23A-1 Schematic. Copyright © 2012 by Despatch Industries. All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
LBB Series Oven Owner’s Manual Version 15 APPENDICES 67 Figure 29. LBB1-23B-1 Schematic. Copyright © 2012 by Despatch Industries. All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
LBB Series Oven Owner’s Manual Version 15 APPENDICES 68 Figure 30. LBB1-43A-1 Schematic. Copyright © 2012 by Despatch Industries. All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
LBB Series Oven Owner’s Manual Version 15 APPENDICES 69 Figure 31. LBB1-43B-1 Schematic. Copyright © 2012 by Despatch Industries. All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
LBB Series Oven Owner’s Manual Version 15 APPENDICES 70 Figure 32. LBB1-69A-1 Schematic. Copyright © 2012 by Despatch Industries. All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
LBB Series Oven Owner’s Manual Version 15 APPENDICES 71 Figure 33. LBB1-69B-1 Schematic. Copyright © 2012 by Despatch Industries. All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
LBB Series Oven Owner’s Manual Version 15 APPENDICES 72 Figure 34. LBB2-12-1 Schematic. Copyright © 2012 by Despatch Industries. All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
LBB Series Oven Owner’s Manual Version 15 APPENDICES 73 Figure 35. LBB2-18-1 Schematic. Copyright © 2012 by Despatch Industries. All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
LBB Series Oven Owner’s Manual Version 15 APPENDICES 74 Figure 36. LBB2-27-1 Schematic. Copyright © 2012 by Despatch Industries. All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
LBB Series Oven Owner’s Manual Version 15 75 3rdDraft— Copyright © 2012 by Despatch Industries. All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
