Specification

CONTACT SUPPORT
PHONE: [phone]
EMAIL: [e-mail]
ADDRESS: 8715 Boston place, Rancho Cucamonga, CA. 91730
www.designelementusa.com
• Avoid using any type of rough cleaning material on top of the cabinet
nish.
• Use mild liquid soap and water-dampened soft cloth to remove stains from
the cabinet and to clean the countertop.
• For the glass part of the mirror, use ammonia-free cleaning products.
CARE AND CLEANING
•Please go through this entire manual before attempting to assemble,
operate or install the product.
•During installation, handle the countertop and sink with optimum care.
•Do not use the vanity instantly after installation. Once you have applied
glue to attach the countertop and sink, wait for approximately 24 hours to
let it dry.
•When scrubbing the cabinet, make sure you do not remove or scratch
the nish.
SAFETY AND PRECAUTIONS
!
While turning around the double sink counter tops, always add
support from the centre for safety
!
While turning around the double sink counter tops, always add
support from the centre for safety
1.
2.
3.
4.
Installing The Drain On The Sink
4. Now that the drain is installed, you can connect the trap onto the drain.
3. Tie up the rubber and metal mounting rings over the drain opening from beneath
the sink.
2. For only the overow sinks, make sure that the hole on the drain is aligned with
the overow hole on the sink.
1. After you have installed the sink and countertop on the cabinet, put the drain
assembly inside the hole in the sink and x it rmly.
1.
2.
Attaching Counter Top To Cabinet
2. Place the counter top on top of the
cabinet.
1. Apply continuous stream of quality
silicon glue on top of the cabinet
contact area.
1.
2.
3.
4.
4. Tie up screws positioned at the respective places on the counter top.
5. Don’t use the sink instantly. Wait for 24 hours for the Silicon glue to dry.
3. Put the glued sink over the cutout and attach it rmly.
2. Turn the counter top upside down and provide support from beneath.
(Note: While turning around the double sink counter tops, always add support from the
centre for safety)
1. Apply continuous stream of silicon glue on circumference of the sink.
Attaching Sink To Counter Top
12"or 16"
1.
2.
3.
4.
Hanging Mirror On The Wall
1. Measure the distance between the screw holes from the back of the mirror.
2. Find the studs on the wall. They are normally 12” to 16” apart from each other.
Drill two holes on the studs as per your measurement.
3. Insert the plastic plugs into the drilled holes. Insert screws into the plastic plugs.
Leave the screws at least 0.5” – 0.75” inches outside.
4. Hang the mirror on to the screws.
WARRANTY
Design Element warrants cabinets, mirrors, nishes and ttings to be free
from defects in workmanship and materials under normal use and service
for a period of one (1) year.
Please report any damage or missing pieces of your vanity to us immedi-
ately. These things must be reported no later than 30 days from the date of
delivery.
PACKING LIST
• Pre-assembled cabinet
• Countertop
• 2 Sinks
• 1 Mirrors
• Mirror mounting screws
• Drain
• Instruction Manual
BACK
FRONT
DEC096
COLLECTION: Designer’s Pick
DIMENSIONS: W 61” | D 22” | H 35”
SKU CODE:
INSTRUCTION MANUAL
DRAWER
19 1/4”
15.6”
4 5/8”
57”
61”
60 5/8”
30 1/4
39 1/2”
35”
29 1/8”
19 3/4” 19 3/4”9” 9”
11”
20 1/4”
9 1/4”
15 3/8
