OWNER'S OPERATION AND INSTALLATION MANUAL B-VENT DECORATIVE GAS FIREPLACE P324E, VP324E, P325E(B),VP325E(B)

108794-01C
13
13
For more information, visit www.desatech.com
For more information, visit www.desatech.com
LOG PLACEMENT FOR P325E(B)/VP325E(B)
MODLES
1. Place large back log (log 1) onto grate making sure notches
rest over grate (see Figure 25).
2. Place log 2 onto front right side of grate. Gently insert peg on
back of log 2 into hole on right front of log 1 (see Figure 25).
3. Insert peg on back of log 3 into hole on left front of log 1 (see
Figure 26). Log 3 will rest between first two grate fingers on
left of grate assembly (see Figure 26).
Figure 25 - Installing Logs 1 and 2
Figure 26 - Installing Log 3
Log 1
Log 2
Log 3
Log 1
Figure 27 - Installing Logs 4 and 5
Figure 28 - Logs Installed
Log 5
INSTALLATION
Continued
NOTICE: Do not put lava rock inside the burner pan or
around the air mixer fitting. Placing lava rock inside the
burner pan or blocking the openings of the propane/LP
air-mixer could cause performance problems.
Log 4
Log 1
Log 3
4. Insert peg on back of log 4 into hole on top left of log 1. Rest
the front of log 4 on the grate as shown in Figure 27.
5. Insert peg on back of log 5 into hole on the top right of log 1
(see Figure 27). Rest the bottom of log 5 on grate as shown in
Figure 28.
To enhance the look of the hearth you may optionally place the lava
rock provided around the front and sides of the burner.
INSTALLATION
Log Placement for P325E/VP325E Models
