REMOVING THE HUB BEARINGS
- Check all bearings (wear, clearance and noise). In case of
anomalies, proceed as follows.
- To remove the 3 15-mm bearings (2 on the crankcase and
1 on the hub cover) use the specific removing tool.
Specific tooling
001467Y01315-mm pliers
REMOVING THE WHEEL AXLE BEARINGS
- Remove the snap ring from the hub cover outside.
- Support the hub cover and eject the bearing.
- Remove the oil guard using the specific tools, as shown in
the figure.
Specific tooling
020376Y Handle for punches
020477Y Adapter 37 mm
020483Y 30 mm guide
020359Y 42 x 47 mm hub bearing fitting adaptor
REMOVING THE WHEEL AXLE BEARINGS
