HEADLIGHT ADJUSTMENT

Proceed as follows:

1. Position the vehicle in riding conditions, and with the tyres

inflated at the prescribed pressure, on a horizontal surface

10m away from a half-lit white screen, ensuring the vertical

axis of the vehicle is perpendicular to the screen;

2. Turn on the headlight and check the distance between the

ground and the horizontal line which separates the lit area

from the dark region, is no more than 9/10 and not less than

7/10 of the height of the headlight, measured from the

ground;

3. If this is not the case, adjust the headlight via screw «A»,

which may be reached by removing the front grid.

WARNING

THE PROCEDURE DESCRIBED ABOVE COMPLIES WITH THE

“EURONORM” CONCERNING THE MAX. AND MIN. HEIG-

HT OF THE LIGHT BEAM OF A ROAD VEHICLE. PLEASE

CHECK WITH THE LOCAL AUTHORITIES FOR WHAT REQUI-

REMENTS MUST BE FULFILLED IN EVERY SINGLE COUNTRY

WHERE THE VEHICLE IS TO BE USED.

SAS FILTERS INSPECTION AND CLEANING

ENGINE 250

- Remove the two screws shown in the picture.
