CHECK
- Move the vehicle to a flat ground and rest it on the stand.
- Unscrew the oil bar, dry it with a clean cloth and reinsert it,
screwing it in thoroughly.
- Extract the bar and check that the oil level reaches the se-
cond notch of the bar from the bottom.
- Screw the oil bar back on, checking that it is tightly in place.
Recommended products
Oil SAE 80W/90 of higher quality than API GL3 specifications
Locking torques (N*m)
Hub oil exhaust cap 15÷17
REPLACEMENT
- Remove oil filler plug “A”.
- Unscrew oil drain plug “B” and drain all the oil.
- Retighten the oil drain plug and then fill the hub with fresh
oil.
Recommended products
Rear hub oil
SAE 80W/90 Oil that passes API GL3 specifications
Locking torques (N*m)
Hub oil drain screw 15 - 17 Nm
AIR FILTER
- Remove the left footboard and the left side pan- el as des-
cribed in Chapter Bodywork.
- Remove the cleaner cap after loosening the 9 fixing
screws.
- Pull out the filter element.
- Replace the air filter with a new one.
